3.0 MODULAR SUPPORT SYSTEM 3.1.2 MT BEAM AND COLUMN LOAD TABLES
Modular Support Systems Technical Guide, Edition 1
Table 16- MT-30 Allowable Beam Loads: X-axis Bending 1, 2, 3, 4, 5, 6
Span in( cm)
Max Allowable Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
24
585
0.11
585
535
355
( 61.0)
( 2,602)
( 0.28)
( 2,602)
( 2,375)
( 1,575)
36
390
0.25
315
235
155
( 91.4)
( 1,735)
( 0.63)
( 1,400)
( 1,045)
( 685)
48
290
0.44
175
130
85
( 121.9)
( 1,290)
( 1.12)
( 775)
( 575)
( 375)
60
235
0.69
110
85
55
( 152.4)
( 1,045)
( 1.74)
( 485)
( 375)
( 240)
72
195
0.99
75
55
35
( 182.9)
( 867)
( 2.51)
( 330)
( 240)
( 155)
84
( 213.4)
165
( 734)
1.35
( 3.42)
55
( 240)
40
( 175)
-
96
( 243.8)
145
( 645)
1.76
( 4.46)
40
( 175)
30
( 130)
-
108
( 274.3)
130
( 578)
2.22
( 5.65)
35
( 155)
-
-
120
( 304.8)
115
( 512)
2.75
( 6.97)
-
-
-
144
( 365.8)
95
( 423)
3.95
( 10.04)
-
-
-
168
( 426.7)
80
( 356)
5.38
( 13.67)
-
-
-
192
( 487.7)
70
( 311)
7.03
( 17.85)
-
-
-
216
( 548.6)
65
( 289)
8.89
( 22.59)
-
-
-
240
( 609.6)
55
( 245)
10.98
( 27.89)
-
-
-
Table 17- MT-30 Allowable Beam Loads: Y-axis Bending 1, 2, 3, 4, 5, 6
Span in( cm)
Max Allowable Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
24
1,260
0.06
1,260
1,260
1,260
( 61.0)
( 5,605)
( 0.15)
( 5,605)
( 5,605)
( 5,605)
36
840
0.14
840
840
610
( 91.4)
( 3,736)
( 0.35)
( 3,736)
( 3,736)
( 2,710)
48
630
0.24
630
515
345
( 121.9)
( 2,802)
( 0.62)
( 2,802)
( 2,290)
( 1,530)
60
505
0.38
440
330
220
( 152.4)
( 2,246)
( 0.97)
( 1,955)
( 1,465)
( 975)
72
420
0.55
305
230
150
( 182.9)
( 1,868)
( 1.39)
( 1,355)
( 1,020)
( 665)
84
360
0.75
225
165
110
( 213.4)
( 1,601)
( 1.90)
( 1,000)
( 730)
( 485)
96
315
0.98
170
125
85
( 243.8)
( 1,401)
( 2.48)
( 755)
( 555)
( 375)
108
280
1.24
135
100
65
( 274.3)
( 1,245)
( 3.14)
( 600)
( 440)
( 285)
120
250
1.52
110
80
55
( 304.8)
( 1,112)
( 3.87)
( 485)
( 355)
( 240)
144
210
2.20
75
55
35
( 365.8)
( 934)
( 5.58)
( 330)
( 240)
( 155)
168
( 426.7)
180
( 801)
2.99
( 7.59)
55
( 240)
40
( 175)
-
192
( 487.7)
155
( 689)
3.90
( 9.91)
40
( 175)
30
( 130)
-
216
( 548.6)
140
( 623)
4.94
( 12.55)
30
( 130)
-
-
240
( 609.6)
125
( 556)
6.10
( 15.49)
-
-
-
Table 18- MT-30 Allowable Column Loads 1, 2, 6, 7, 8, 9
Unbraced Height in( cm)
Max Allowable Load at Channel Face lbs( N)
K = 0.65 lbs( N)
Maximum Column Load Applied at C. G.
K = 0.80 lbs( N)
K = 1.0 lbs( N)
K = 1.2 lbs( N)
24
2,280
6,045
5,600
5,020
4,485
( 61.0)
( 10,140)
( 26,885)
( 24,910)
( 22,330)
( 19,950)
36
1,860
5,090
4,485
3,415
2,455
( 91.4)
( 8,270)
( 22,640)
( 19,950)
( 15,190)
( 10,920)
48
1,385
4,120
3,080
1,985
1,380
( 121.9)
( 6,160)
( 18,325)
( 13,700)
( 8,825)
( 6,135)
60
( 152.4)
1,055
( 4,690)
2,995
( 13,320)
1,985
( 8,825)
1,270
( 5,645)
**
72
( 182.9)
820
( 3,645)
2,090
( 9,295)
1,380
( 6,135)
**
**
84
( 213.4)
**
1,535
( 6,825)
**
**
**
96
( 243.8)
**
1,175
( 5,225)
**
**
**
108
( 274.3)
**
**
**
**
**
120
( 304.8)
**
**
**
**
**
144
( 365.8)
**
**
**
**
**
Notes: 1. Loads are based on ICC-ES ESR-5019 and AISI S100-16, the North American
Specification for the Design of Cold-Formed Steel Structural Members. 2. Safety factors for flexure and compression are 1.67 and 1.80, respectively. 3. Allowable beam loads in table are given in total uniform load( W * Span) and based on a uniformly loaded condition with simply supported ends. For other loading and support conditions, see page 32 for applicable load and deflection modification factors.
4. Beams spans in table are assumed to be sufficiently laterally braced. Unbraced spans may reduce beam load carrying capacity. See page 49 for reduction factors for unbraced conditions.
5. Profile weight, 1.1 lbs / ft( 16.09 N / m), must be deducted from allowable beam load values.
6. Multiply tabulated load values by 1.5 to obtain Load and Resistance Factor
Design( LRFD) values. 7. C. G. is the‘ Center of Gravity’ of the cross section. 8. ** indicates KL / r for compression exceeds 200. 9. Maximum allowable load at channel face assumes K value of 0.8.
��
����“)
�����“)
�
��������“)
����
��������“) ��
��������“) ���
�����
�����“)
�������
