Anchor Fastening Technical Guide , Edition 22
Table 57 — Hilti HIT-HY 200 V3 adhesive design strength with concrete / bond failure for Hilti HIS-N and HIS-RN internally threaded inserts in uncracked concrete 1 , 2 , 3 , 4 , 5 , 6 , 7 , 8 , 9
Tension — ФN n Shear — ФV n
Thread size
3 / 8-16 UNC
1 / 2-13 UNC
5 / 8-11 UNC
3 / 4-10 UNC
Effective embedment in . ( mm ) ƒ ́c = 2,500 psi ( 17.2 MPa ) lb ( kN ) ƒ ́c = 3,000 psi ( 20.7 MPa ) lb ( kN ) ƒ ́c = 4,000 psi ( 27.6 MPa ) lb ( kN ) ƒ ́c = 6,000 psi ( 41.4 MPa ) lb ( kN ) ƒ ́c = 2,500 psi ( 17.2 MPa ) lb ( kN ) ƒ ́c = 3,000 psi ( 20.7 MPa ) lb ( kN ) ƒ ́c = 4,000 psi ( 27.6 MPa ) lb ( kN ) ƒ ́c = 6,000 psi ( 41.4 MPa ) lb ( kN )
4-3 / 8
7,140
7,820
9,030
11,060
15,375
16,840
19,445
23,815
( 111 )
( 31.8 )
( 34.8 )
( 40.2 )
( 49.2 )
( 68.4 )
( 74.9 )
( 86.5 )
( 105.9 )
5
8,720
9,555
11,030
13,510
18,785
20,575
23,760
29,100
( 127 )
( 38.8 )
( 42.5 )
( 49.1 )
( 60.1 )
( 83.6 )
( 91.5 )
( 105.7 )
( 129.4 )
6-3 / 4
13,680
14,985
17,305
21,190
29,460
32,275
37,265
45,645
( 171 )
( 60.9 )
( 66.7 )
( 77.0 )
( 94.3 )
( 131.0 )
( 143.6 )
( 165.8 )
( 203.0 )
8-1 / 8
18,065
19,790
22,850
27,985
38,910
42,620
49,215
60,275
( 206 )
( 80.4 )
( 88.0 )
( 101.6 )
( 124.5 )
( 173.1 )
( 189.6 )
( 218.9 )
( 268.1 )
3.2.2
Table 58 — Hilti HIT-HY 200 V3 adhesive design strength with concrete / bond failure for Hilti HIS-N and HIS-RN internally threaded inserts in cracked concrete 1 , 2 , 3 , 4 , 5 , 6 , 7 , 8 , 9
Tension — ФN n Shear — ФV n
Thread size
3 / 8-16 UNC
1 / 2-13 UNC
5 / 8-11 UNC
3 / 4-10 UNC
Effective embedment in . ( mm ) ƒ ́c = 2,500 psi ( 17.2 MPa ) lb ( kN ) ƒ ́c = 3,000 psi ( 20.7 MPa ) lb ( kN ) ƒ ́c = 4,000 psi ( 27.6 MPa ) lb ( kN ) ƒ ́c = 6,000 psi ( 41.4 MPa ) lb ( kN ) ƒ ́c = 2,500 psi ( 17.2 MPa ) lb ( kN ) ƒ ́c = 3,000 psi ( 20.7 MPa ) lb ( kN ) ƒ ́c = 4,000 psi ( 27.6 MPa ) lb ( kN ) ƒ ́c = 6,000 psi ( 41.4 MPa ) lb ( kN )
4-3 / 8
5,050
5,335
5,815
6,570
10,880
11,495
12,530
14,150
( 111 )
( 22.5 )
( 23.7 )
( 25.9 )
( 29.2 )
( 48.4 )
( 51.1 )
( 55.7 )
( 62.9 )
5
6,175
6,765
7,815
9,570
13,305
14,575
16,830
20,610
( 127 )
( 27.5 )
( 30.1 )
( 34.8 )
( 42.6 )
( 59.2 )
( 64.8 )
( 74.9 )
( 91.7 )
6-3 / 4
9,690
10,615
12,255
15,010
20,870
22,860
26,395
32,330
( 171 )
( 43.1 )
( 47.2 )
( 54.5 )
( 66.8 )
( 92.8 )
( 101.7 )
( 117.4 )
( 143.8 )
8-1 / 8
12,795
14,015
16,185
19,825
27,560
30,190
34,860
42,695
( 206 )
( 56.9 )
( 62.3 )
( 72.0 )
( 88.2 )
( 122.6 )
( 134.3 )
( 155.1 )
( 189.9 )
1 See section 3.1.8 for explanation on development of load values . 2 See section 3.1.8 to convert design strength ( factored resistance ) value to ASD value . 3 Linear interpolation between embedment depths and concrete compressive strengths is not permitted . 4 Apply spacing , edge distance , and concrete thickness factors in tables 60 - 61 as necessary to the above values . Compare to the steel values in table 59 . The lesser of the values is to be used for the design .
5 Data is for temperature range A : Max . short term temperature = 130 ° F ( 55 ° C ), max . long term temperature = 110 ° F ( 43 ° C ). For temperature range B : Max . short term temperature = 176 ° F ( 80 ° C ), max . long term temperature = 110 ° F ( 43 ° C ) multiply above values by 0.92 . For temperature range C : Max . short term temperature = 248 ° F ( 120 ° C ), max . long term temperature = 162 ° F ( 72 ° C ) multiply above values by 0.78 . Short-term elevated concrete temperatures are those that occur over brief intervals , e . g ., as a result of diurnal cycling . Long term concrete temperatures are roughly constant over significant periods of time . 6 Tabular values are for dry concrete conditions . For water saturated concrete multiply design strength ( factored resistance ) by 0.85 . 7 Tabular values are for short term loads only . For sustained loads including overhead use , see section 3.1.8 . 8 Tabular values are for normal-weight concrete only . For lightweight concrete multiply design strength ( factored resistance ) by λ a as follows :
For sand-lightweight , λ a = 0.51 . For all-lightweight , λ a
= 0.45 . 9 Tabular values are for static loads only . Seismic design is not permitted for uncracked concrete . For seismic loads , multiply cracked concrete tabular values in tension and shear by α seis
=
0.69 . See section 3.1.8 for additional information on seismic applications .
Table 59 — Steel design strength for steel bolt and cap screw for Hilti HIS-N and HIS-RN internally threaded inserts 1 , 2 , 3
Thread size
3 / 8-16 UNC
1 / 2-13 UNC
5 / 8-11 UNC
3 / 4-10 UNC
Tensile 4
ϕN sa lb ( kN )
ASTM A193 B7
Shear 5
ϕV sa lb ( kN )
Seismic Shear 6
ϕV sa , eq lb ( kN )
Tensile 4
ϕN sa lb ( kN )
ASTM A193 Grade B8M stainless steel
Shear 5
ϕV sa lb ( kN )
Seismic Shear 6
ϕV sa , eq lb ( kN ) 6,300 3,490 2,445 5,540 3,070 2,150 ( 28.0 ) ( 15.5 ) ( 10.9 ) ( 24.6 ) ( 13.7 ) ( 9.6 ) 11,530 6,385 4,470 10,145 5,620 3,935 ( 51.3 ) ( 28.4 ) ( 19.9 ) ( 45.1 ) ( 25.0 ) ( 17.5 ) 18,365 10,170 7,120 16,160 8,950 6,265 ( 81.7 ) ( 45.2 ) ( 31.6 ) ( 71.9 ) ( 39.8 ) ( 27.9 ) 27,180 15,055 10,540 23,915 13,245 9,270 ( 120.9 ) ( 67.0 ) ( 46.9 ) ( 106.4 ) ( 58.9 ) ( 41.2 )
1 See section 3.1.8 to convert design strength ( factored resistance ) value to ASD value . 2 Hilti HIS-N and HIS-RN inserts with steel bolts are to be considered brittle steel elements . 3 Table values are the lesser of steel failure in the HIS-N insert or inserted steel bolt . 4 Tensile = ϕA se , N f uta as noted in ACI 318 Chapter 17 . 5 Shear values determined by static shear tests with ϕV sa
≤ ϕ 0.60 A se , V f uta as noted in ACI 318 Chapter 17 .
6 Seismic Shear = α V , seis ϕ Vsa
: Reduction for seismic shear only . See section 3.1.8 for additional information on seismic applications .
