Table 21 — Hilti KWIK Bolt 3 stainless steel factored resistance with concrete / pullout failure in uncracked concrete 1 , 2 , 3 , 4 , 5
Nominal anchor diameter in .
1 / 4
3 / 8
1 / 2
5 / 8
3 / 4
1
Effective embed . in . ( mm )
Nominal embed . in . ( mm ) ƒ ' c
= 20 MPa ( 2,900psi ) lb ( kN ) ƒ ' c
= 25 MPa ( 3,625 psi ) lb ( kN )
Tension - N r ƒ ' c
= 30 MPa ( 4,350 psi ) lb ( kN ) ƒ ' c
= 40 MPa ( 5,800 psi ) lb ( kN ) ƒ ' c
= 20 MPa ( 2,900 psi ) lb ( kN ) ƒ ' c
= 25 MPa ( 3,625 psi ) lb ( kN )
Shear - V r ƒ ' c
= 30 MPa ( 4,350 psi ) lb ( kN ) ƒ ' c
= 40 MPa ( 5,800 psi ) lb ( kN )
1 1 / 2
1-11 / 16
930
1,040
1,140
1,315
1,300
1,455
1,595
1,840
( 38 )
43
( 4.1 )
( 4.6 )
( 5.1 )
( 5.8 )
( 5.8 )
( 6.5 )
( 7.1 )
( 8.2 )
2
2-5 / 16
2,080
2,325
2,545
2,940
2,380
2,660
2,915
3,365
( 51 )
( 59 )
( 9.2 )
( 10.3 )
( 11.3 )
( 13.1 )
( 10.6 )
( 11.8 )
( 13.0 )
( 15.0 )
2
2 3 / 8
2,315
2,585
2,835
3,275
2,380
2,660
2,915
3,365
( 51 )
( 60 )
( 10.3 )
( 11.5 )
( 12.6 )
( 14.6 )
( 10.6 )
( 11.8 )
( 13.0 )
( 15.0 )
3-1 / 4
3 5 / 8
4,220
4,715
5,165
5,965
9,885
11,050
12,105
13,975
( 83 )
( 92 )
( 18.8 )
( 21.0 )
( 23.0 )
( 26.5 )
( 44.0 )
( 49.2 )
( 53.8 )
( 62.2 )
3-1 / 8
3-9 / 16
4,360
4,875
5,340
6,165
9,175
10,260
11,240
12,980
( 79 )
( 90 )
( 19.4 )
( 21.7 )
( 23.8 )
( 27.4 )
( 40.8 )
( 45.6 )
( 50.0 )
( 57.7 )
4
4-7 / 16
5,480
6,125
6,710
7,750
13,465
15,055
16,490
19,040
( 102 )
( 113 )
( 24.4 )
( 27.2 )
( 29.8 )
( 34.5 )
( 59.9 )
( 67.0 )
( 73.4 )
( 84.7 )
3-3 / 4
4-5 / 16
6,000
6,705
7,345
8,480
12,100
13,530
14,820
17,115
( 95 )
( 110 )
( 26.7 )
( 29.8 )
( 32.7 )
( 37.7 )
( 53.8 )
( 60.2 )
( 65.9 )
( 76.1 )
4-3 / 4
5-9 / 16
7,590
8,485
9,295
10,730
17,395
19,450
21,305
24,600
( 121 )
( 141 )
( 33.8 )
( 37.7 )
( 41.3 )
( 47.7 )
( 77.4 )
( 86.5 )
( 94.8 )
( 109.4 )
4
4-5 / 16
6,730
7,525
8,245
9,520
13,465
15,055
16,490
19,040
( 102 )
( 110 )
( 29.9 )
( 33.5 )
( 36.7 )
( 42.3 )
( 59.9 )
( 67.0 )
( 73.4 )
( 84.7 )
5 3 / 4
5-9 / 16
10,895
12,180
13,340
15,405
23,055
25,780
28,240
32,610
( 146 )
( 141 )
( 48.5 )
( 54.2 )
( 59.3 )
( 68.5 )
( 102.6 )
( 114.7 )
( 125.6 )
( 145.0 )
1 See section 3.1.8 to convert factored resistance value to ASD value . 2 Linear interpolation between embedment depths and concrete compressive strengths is not permitted .
3 Apply spacing , edge distance , and concrete thickness factors in tables 14 to 19 as necessary . Compare to the steel values in table 31 . The lesser of the values is to be used for the design .
4 Tablular values are for normal-weight concrete only . For lightweight concrete multiply design strength by λ a as follows : for sand-lightweight , λ a = 0.68 ; for all-lightweight , λ a
= 0.60 5 Tabular values are for static loads only . Seismic design is not permitted for uncracked concrete .
Table 22 — Steel resistance for Hilti KWIK Bolt 3 hot-dip galvanized carbon steel anchors 1 , 2
Nominal anchor diameter in .
1 / 2
5 / 8
3 / 4
Nominal embedment in . ( mm )
2-1 / 4
Tensile N sar
3 lb ( kN )
Shear V sar
4 lb ( kN ) 2,870
( 57 )
7,930
( 12.8 )
3-1 / 2
( 35.3 )
3,740
( 89 ) ( 16.6 ) 3-1 / 2 ( 89 ) 4-3 / 8 ( 111 ) 4-1 / 4 ( 108 ) 5-1 / 2 ( 140 )
1 See section 3.1.8 to convert design strength value to ASD value .
12,255 ( 54.5 )
17,300 ( 77.0 )
2 KWIK Bolt 3 hot-dip galvanized carbon steel anchors are to be considered ductile steel elements . 3 Tensile N sar
= A se , N ф s f uta
R as noted in ACI 318 Chapter 17 . 4 Shear values determined by static shear tests with V sar
< A se , V ф s
0.6 f uta
R as noted in ACI 318 Chapter 17 .
7,415 ( 33.0 )
10,840 ( 48.2 )
