3.2.7 HAS THREADED RODS AND HIT-Z ANCHOR RODS
Anchor Fastening Technical Guide , Edition 22
Hilti has a full line of threaded rods available in 8 different material and coating types . Our new enhanced carbon steel rods now all meet the requirements of ASTM F1554 , which allows engineers to design ductile fastening points with predictable steel failure for seismic applications in the three most common and relevant steel grades 36 , 55 and 105 .
Hilti still continues to provide the innovative HIT-Z anchor rods with HIT-HY 200 V3 . This Hilti SafeSet system provides the ultimate in safety and load capacity combined with 60 % faster installation due to zero-cleaning .
The following is the technical data and ordering information for diameters up to 1-1 / 4 " and pre-cut lengths . Contact Hilti for additional information on HAS rod diameters up to 2-1 / 2 " and custom lengths .
Specifications and physical properties of Hilti HAS threaded rods and Hilti HIT-Z anchor rods
Threaded Rod Specification |
Units |
Specified Ultimate Strength ,
f uta
Min . Max 6
|
Minimum Specified Yield Strength 0.2 % Offset , f ya
|
f uta / f ya |
Elongation , Min . %
Reduction of Area , Min . %
|
Specification for Nuts and Washers |
3.2.7 |
HAS-V-A307 1 / 4-in . to 5 / 16-in . psi 60,000 37,500
ASTM A307 Grade A 1 , 2 NA ( MPa ) ( 414 ) ( 259 )
1.60 10 -
Nuts : SAE J995 Grade 5 Washers : ASTM F884 , HV and ANSI B18.22.1 Type A Plain
CARBON STEEL
|
36 , 000
HAS-V / HAS-V-36 / HAS-V-36 HDG
|
|
|
|
|
|
|
|
ASTM F1554 , Grade 36 1 , 3 , 9 psi
58 , 000
80 , 000
|
|
|
|
|
|
|
|
|
|
|
1.61 |
23 |
40 |
( MPa ) ( 400 ) ( 552 ) ( 248 )
|
55 , 000
HAS-E-55 / HAS-E-55 HDG
|
|
|
|
|
|
|
ASTM F1554 , Grade 55 1 , 3 , 9 psi
75 , 000
95 , 000
|
|
|
|
|
|
|
|
|
|
1.36 |
21 |
( MPa ) ( 517 ) ( 655 ) ( 379 )
HAS-B 105 / HAS-B-105 HDG |
|
|
|
|
ASTM A193 , Grade B7 1 , 4
|
psi |
125,000 ( 7 ) |
150,000 |
105,000 |
ASTM F1554 , Grade 105 1 , 3 , 9
|
|
|
|
|
1.19
30 ( 3 / 8 " - 2 ")
22 ( 2-1 / 4 " - 2-1 / 2 ")
16 ( B7 ) 50 ( B7 )
( MPa ) ( 862 ) ( 7 ) ( 1,034 ) ( 724 ) 15 ( Gr . 105 ) 45 ( Gr . 105 )
HIT-Z Anchor rod ( HIT-HY 200 V3 only ) psi 94,200 75,300
Unalloyed carbon steel 1 NA ( MPa ) ( 650 ) ( 519 )
1.25 8 20
Nuts : ASTM A194 / 194M , Grade 2H , Heavy or ASTM A563-15 Grade A , Heavy Washers : ASTM F436 Type 1 and ANSI B18.22.1 Type A Plain
Nuts : ASTM A194 / 194M , Grade 2H , Heavy or ASTM A563-15 Grade C Washers : ASTM F436 Type 1 and ANSI B18.22.1 Type A Plain
Nuts : ASTM A563 Gr . A Washers : ASTM F844 , HV and ANSI B18.22.1 Type A Plain
HAS-R 304 / 316 3 / 8-in . 5 / 8-in . AISI Type 304 / 316 ASTM F 593 CW1 5 psi 100,000 150,000 65,000 ( MPa ) ( 690 ) ( 1,034 ) ( 448 )
1.54 20 -
STAINLESS STEEL
HAS-R 304 / 316 3 / 4-in . to 1-in . AISI Type 304 / 316 ASTM F 593 CW2 5
HAS-R 304 / 316 1 / 4-in . to 5 / 16-in . and 1-1 / 8 " to 2-in . ASTM A193 Grade8 ( M ), Class 1 4
HIT-Z Anchor rod ( HIT-HY 200 V3 only ) Grade 316 psi 85,000 140,000 45,000 ( MPa ) ( 586 ) ( 966 ) ( 310 )
psi 75,000 ( 8 ) 30,000
NA ( MPa ) ( 517 ) ( 8 ) ( 207 )
psi 94,200 75,300
NA ( MPa ) ( 650 ) ( 519 )
1.89 25 -
2.50 ( 7 ) 30 50
1.25 8 20
Anchor Fastening Technical Guide Edition 22 | 3.0 ANCHORING SYSTEMS | 3.2.7 HAS AND HIT-Z ANCHOR RODS Hilti , Inc . 1-800-879-8000 | en español 1-800-879-5000 | www . hilti . com | Hilti ( Canada ) Corporation | www . hilti . ca | 1-800-363-4458
Nuts : ASTM F594 Washers : ASTM A240 and ANSI B18.22.1 Type A Plain
1 All electroplated carbon steel threaded rods are zinc plated in accordance with ASTM F1941 Fe / Zn 5 AN , with nuts and washers zinc plated in accordance with ASTM B633 SC 1 Type III . All hot-dipped galvanized threaded rods , nuts , and washers are zinc plated in accordance with ASTM F2329 . 2 Standard Specification for Carbon Steel Bolts and Studs , 60,000 psi Tensile Strength . 3 Standard Specification for Anchor Bolts , Steel , 36 , 55 , and 105-ksi Yield Strength . 4 Standard Specification for Alloy-Steel and Stainless Steel Bolting Materials for High-Temperature Service . 5 Standard Steel Specification for Stainless Steel Bolts , Hex Cap Screws , and Studs . 6 Maximum specified steel strength according to ASTM standard . NA indicates that ASTM standard does not publish a maximum value . 7 For designs according to CSA A23.3 Annex D , the maximum value of f uta is 860 MPa ( 124,700 psi ) per clause D . 6.1.2 . 8 For calculating steel strength , ACI 318 section 17.4.1.2 and CSA A23.3 clause D . 6.1.2 limit the ultimate strength to 1.9 f ya
.
Thus , f uta = 57,000 psi ( 393 MPa ) for calculation purposes when determining steel strength in tension ( N sa
) and shear ( V sa
). 9 3 / 8-inch dia . threaded rods are not included in the ASTM F1554 standard . Hilti 3 / 8-inch dia . HAS-V-36 , HAS-E-55 , and HAS-B-105 ( incl . HDG ) threaded rods meet the chemical composition and mechanical property requirements of ASTM F1554 .
