Table 33 — Hilti HIT-ICE adhesive design strength with concrete / bond failure for Hilti HIS-N and HIS-RN internally threaded inserts in uncracked concrete 1 , 2 , 3 , 4 , 5 , 6 , 7 , 8
Tension — ФN n Shear — ФV n
Thread size
3 / 8-16 UNC
1 / 2-13 UNC
5 / 8-11 UNC
3 / 4-10 UNC
Effective embedment in . ( mm ) ƒ ́c = 2,500 psi ( 17.2 MPa ) lb ( kN ) ƒ ́c = 3,000 psi ( 20.7 MPa ) lb ( kN ) ƒ ́c = 4,000 psi ( 27.6 MPa ) lb ( kN ) ƒ ́c = 6,000 psi ( 41.4 MPa ) lb ( kN ) ƒ ́c = 2,500 psi ( 17.2 MPa ) lb ( kN ) ƒ ́c = 3,000 psi ( 20.7 MPa ) lb ( kN ) ƒ ́c = 4,000 psi ( 27.6 MPa ) lb ( kN ) ƒ ́c = 6,000 psi ( 41.4 MPa ) lb ( kN )
4-3 / 8 |
4,080 |
4,155 |
4,275 |
4,450 |
10,380 |
10,570 |
10,880 |
11,330 |
( 111 ) |
( 18.1 ) |
( 18.5 ) |
( 19.0 ) |
( 19.8 ) |
( 46.2 ) |
( 47.0 ) |
( 48.4 ) |
( 50.4 ) |
5 |
7,070 |
7,200 |
7,410 |
7,720 |
15,230 |
15,510 |
15,965 |
16,625 |
( 127 ) |
( 31.4 ) |
( 32.0 ) |
( 33.0 ) |
( 34.3 ) |
( 67.7 ) |
( 69.0 ) |
( 71.0 ) |
( 74.0 ) |
6-3 / 4 |
11,580 |
11,790 |
12,135 |
12,640 |
24,940 |
25,395 |
26,140 |
27,220 |
( 171 ) |
( 51.5 ) |
( 52.4 ) |
( 54.0 ) |
( 56.2 ) |
( 110.9 ) |
( 113.0 ) |
( 116.3 ) |
( 121.1 ) |
8-1 / 8 |
15,010 |
15,285 |
15,735 |
16,385 |
32,330 |
32,925 |
33,885 |
35,290 |
( 206 ) |
( 66.8 ) |
( 68.0 ) |
( 70.0 ) |
( 72.9 ) |
( 143.8 ) |
( 146.5 ) |
( 150.7 ) |
( 157.0 ) |
3.2.5
Table 34 — Hilti HIT-ICE adhesive design strength with concrete / bond failure for Hilti HIS-N and HIS-RN internally threaded inserts in cracked concrete 1 , 2 , 3 , 4 , 5 , 6 , 7 , 8 , 9
Tension — ФN n Shear — ФV n
Thread size
3 / 8-16 UNC
1 / 2-13 UNC
Effective embedment in . ( mm ) ƒ ́c = 2,500 psi ( 17.2 MPa ) lb ( kN ) ƒ ́c = 3,000 psi ( 20.7 MPa ) lb ( kN ) ƒ ́c = 4,000 psi ( 27.6 MPa ) lb ( kN ) ƒ ́c = 6,000 psi ( 41.4 MPa ) lb ( kN ) ƒ ́c = 2,500 psi ( 17.2 MPa ) lb ( kN ) ƒ ́c = 3,000 psi ( 20.7 MPa ) lb ( kN ) ƒ ́c = 4,000 psi ( 27.6 MPa ) lb ( kN ) ƒ ́c = 6,000 psi ( 41.4 MPa ) lb ( kN )
4-3 / 8 |
1,720 |
1,750 |
1,805 |
1,875 |
4,380 |
4,460 |
4,590 |
4,780 |
( 111 ) |
( 7.7 ) |
( 7.8 ) |
( 8.0 ) |
( 8.3 ) |
( 19.5 ) |
( 19.8 ) |
( 20.4 ) |
( 21.3 ) |
5 |
2,480 |
2,525 |
2,600 |
2,710 |
5,345 |
5,440 |
5,600 |
5,835 |
( 127 ) |
( 11.0 ) |
( 11.2 ) |
( 11.6 ) |
( 12.1 ) |
( 23.8 ) |
( 24.2 ) |
( 24.9 ) |
( 26.0 ) |
1 See section 3.1.8 for explanation on development of load values . 2 See section 3.1.8 to convert design strength ( factored resistance ) value to ASD value . 3 Linear interpolation between embedment depths and concrete compressive strengths is not permitted . 4 Apply spacing , edge distance , and concrete thickness factors in tables 36-37 as necessary to the above values . Compare to the steel values in table 35 .
The lesser of the values is to be used for the design .
5 Data is for temperature range A : Max . short term temperature = 130 ° F ( 55 ° C ), max . long term temperature = 110 ° F ( 43 ° C ). Short-term elevated concrete temperatures are those that occur over brief intervals , e . g ., as a result of diurnal cycling . Long term concrete temperatures are roughly constant over significant periods of time . 6 Tabular values are for dry concrete conditions . For water saturated concrete multiply design strength ( factored resistance ) by 0.85 . 7 Tabular values are for short term loads only . For sustained loads including overhead use , see section 3.1.8.8 . 8 Tabular values are for normal-weight concrete only . For lightweight concrete multiply design strength ( factored resistance ) by λ a as follows :
For sand-lightweight , λ a = 0.51 . For all-lightweight , λ a
= 0.45 . 9 Tabular values are for static loads only . Seismic applications are not permitted .
Table 35 — Steel design strength for steel bolt / cap screw for Hilti HIS-N and HIS-RN internally threaded inserts 1 , 2 , 3
Thread size
3 / 8-16 UNC
1 / 2-13 UNC
5 / 8-11 UNC
3 / 4-10 UNC
Tensile 4
ϕN sa lb ( kN )
ASTM A193 B7
ACI 318 Chapter 17 Based Design
Shear 5
ϕV sa lb ( kN )
ASTM A193 Grade B8M stainless steel
Tensile 4
ϕN sa lb ( kN )
Shear 5
ϕV sa lb ( kN ) 6,300 3,490 5,540 3,070 ( 28.0 ) ( 15.5 ) ( 24.6 ) ( 13.7 ) 10,525 6,385 10,145 5,620 ( 46.8 ) ( 28.4 ) ( 45.1 ) ( 25.0 ) 17,500 10,170 16,160 8,950 ( 77.8 ) ( 45.2 ) ( 71.9 ) ( 39.8 ) 17,785 15,055 23,915 13,245 ( 79.1 ) ( 67.0 ) ( 106.4 ) ( 58.9 )
1 See section 3.1.8 to convert design strength value to ASD value . 2 Hilti HIS-N and HIS-RN inserts with steel bolts are to be considered brittle steel elements . 3 Table values are the lesser of steel failure in the HIS-N insert or inserted steel bolt . 4 Tensile = ϕA se , N f uta as noted in ACI 318 Chapter 17 . 5 Shear = ϕ 0.60 A se , V f uta as noted in ACI 318 Chapter 17 . For 3 / 8-in diameter insert shear = ϕ 0.50 A se , V f uta
