• an easy clip mechanism to secure into position and remain fixed without the need for silicone
• assurance that any water ingress into the glazing channel will run below MSBP and out via the window or door drainage system and stops water / moisture build up and freezing in the winter
• prevention of water contact with the Insulating Glazing Unit( IGU) maintaining a distance between the water and IGU edge
• easier and cleaner for installation
|
Designed to fully integrate with the Glazpart range of flat packers, the MSBP also has the same functional benefits as Glazpart’ s current range of bridge packers.
Another welcome introduction in 2025, was the Modular Vent which is perfect for fabricators manufacturing PVC-U vertical sliders in the heritage sector and for smaller window or doors. It is the best trickle vent in the market for
|
watertightness( at 1000 Pa). The Spring Clip fitting( no screws) saves on installation time and the vent, though one of the shortest width trickle vents available achieves a 2000 EQA performance for each module fitted. The Modular Vent, just like Glazpart’ s award winning Link Vent range has hundreds of colour and finish options. |
Made for Triple Glazing
As triple glazing becomes increasingly popular, particularly in new build, fabricators have to factor in all the challenges faced when manufacturing triple glazed windows and doors.
The growth in triple glazing can be attributed to several factors. Firstly, the regulatory framework around the Future Homes standard, which although doesn’ t make triple glazing mandatory, it does lean towards toward triple glazing as the best option for compliance in new build.
The other main reasons for the popularity of triple glazed windows and doors
|
are the multiple advantages for homeowners such as, greater insulation and energy efficiency, noise reduction and reduced condensation.
Though it has many benefits one of the main challenges with triple glazing is the additional weight Of the sealed unit caused by an extra pane of glass. The extra weight is a serious consideration for all triple glazing fabricators, not just during the window manufacturing process, but also while their windows and doors are in transit and being installed.
To ensure the weight of the IGU( Insulated Glass Unit) is supported and handled carefully during window installation, the right flat packers are vitally important to avoid accidents( even relatively minor incidents) that could cause product damage and also put employee safety at risk.
Glazpart, provides a range of glazing accessories which focus on compliance and safety to help fabricators to do the job safely and securely.
When manufacturing a triple glazed window or door, the extra weight can be best managed by using Glazpart’ s extensive range of 34mm to 50mm wide flat packers( often referred to in the standards as setting or location blocks).
Glazpart’ s range of flat packers are colour coded and are part of a fully integrated and comprehensive range of glazing accessories that includes, frame packers, bridge packers, run-up blocks, glazing shovels and corner protectors.
The flat packers are specifically designed to work with bridge packers to prevent slip and to securely pack out the glass in the sash or frame. Applied correctly and within the system, the flat packers support the glazed unit and transfer the weight of the glass to the
|
frame. The bridge packer then allows water droplets from condensation to escape underneath and out through the drain hole covers. The Glazpart ranges of glazing accessories are designed to all work together for all glazing types both double and triple.
Using Glazpart’ s glazing accessories helps fabricators and installers protect windows, doors and glass from damage during fabrication, transit and installation. In addition, for homeowners, the glazing accessories range improves window security, protection and strength when installed correctly to window system manufacturers guidelines with a quality product.
Dean Bradley, Glazpart Sales Director commented on how Glazpart offers“ our extensive glazing accessories range and our market leading trickle vent ranges, makes Glazpart a“ one stop shop” for PVC-U window and door fabricators.”
To find out more about Glazpart’ s products please visit www. glazpart. com or contact Dean Bradley, Sales Director dbradley @ glazpart. co. uk
|
