Installation instructions
Installation Instructions For Use( IFU) are included with each product package. They can also be viewed or downloaded online at www. hilti. com. Because of the possibility of changes, always verify that downloaded FU are current when used. Proper installation is critical to achieve full performance. Training is available on request. Contact Hili Technical Services for applications and conditions not addressed in the IFU.
Ordering information
Description Hole Diameter
Total Length without Anchor Head
Screw Anchor Head Height( in)
Screw Anchor Head Width( in)
Minimum Embedment Depth
KH-EZ P 1 / 4” x1 7 / 8” 1 / 4” 17 / 8 0.13 0.52 1 5 / 8 100 KH-EZ P 1 / 4” x2 5 / 8” 1 / 4” 2 5 / 8 0.13 0.52 1 5 / 8 100 KH-EZ PM 1 / 4” x2 5 / 8” 1 / 4” 2 5 / 8 0.13 0.69 1 5 / 8 100 KH-EZ PM 1 / 4” x1 7 / 8” 1 / 4” 1 7 / 8 0.13 0.69 1 5 / 8 100 KH-EZ PL 1 / 4” X2 5 / 8” 1 / 4” 2 5 / 8 0.18 0.86 1 5 / 8 100 KH-EZ C 1 / 4” x2” 1 / 4” 2 0.16 0.45 1 5 / 8 100 KH-EZ C 1 / 4” x2 1 / 2” 1 / 4” 2 1 / 2 0.16 0.45 1 5 / 8 100 KH-EZ C 1 / 4” x3” 1 / 4” 3 0.16 0.45 1 5 / 8 100 KH-EZ C 1 / 4” x4” 1 / 4” 4 0.16 0.45 1 5 / 8 100 KH-EZ 1 / 4” x1 7 / 8” 1 / 4” 1 7 / 8 0.24 0.44 1 5 / 8 100 KH-EZ 1 / 4” x2 5 / 8” 1 / 4” 2 5 / 8 0.24 0.44 1 5 / 8 100 KH-EZ 1 / 4” x3” 1 / 4” 3 0.24 0.44 1 5 / 8 100 KH-EZ 1 / 4” x3 1 / 2” 1 / 4” 3 1 / 2 0.24 0.44 1 5 / 8 100 KH-EZ 1 / 4” x4” 1 / 4” 4 0.24 0.44 1 5 / 8 100 KH-EZ 3 / 8” x1 7 / 8 3 / 8” 1 7 / 8 0.35 0.56 1 5 / 8 50 KH-EZ 3 / 8” x2 1 / 8” 3 / 8” 2 1 / 8 0.35 0.56 1 5 / 8 50 KH-EZ( CRC) 3 / 8” x3” 3 / 8” 3 0.35 0.56 2 1 / 2 50 KH-EZ 3 / 8” x3 1 / 2” 3 / 8” 3 1 / 2 0.35 0.56 2 1 / 2 50 KH-EZ( CRC) 3 / 8” x4” 3 / 8” 4 0.35 0.56 3 1 / 4 50 KH-EZ( CRC) 3 / 8”” x5” 3 / 8” 5 0.35 0.56 3 1 / 4 50 KH-EZ C 3 / 8” x2 1 / 2” 3 / 8” 2 1 / 2 0.25 0.71 1 5 / 8 50 KH-EZ C 3 / 8” x3” 3 / 8” 3 0.25 0.71 2 1 / 2 50 KH-EZ C 3 / 8” x4” 3 / 8” 4 0.25 0.71 2 1 / 2 50 KH-EZ 1 / 2” x2 1 / 2” 1 / 2” 2 1 / 2 0.48 0.75 2 1 / 4 25 KH-EZ( CRC) 1 / 2” x3” 1 / 2” 3 0.48 0.75 2 1 / 4 25 KH-EZ 1 / 2” x3 1 / 2” 1 / 2” 3 1 / 2 0.48 0.75 2 1 / 4 25 KH-EZ( CRC) 1 / 2” x4” 1 / 2” 4 0.48 0.75 2 1 / 4 25 KH-EZ 1 / 2” x4 1 / 2” 1 / 2” 4 1 / 2 0.48 0.75 3 25 KH-EZ( CRC) 1 / 2” x5” 1 / 2” 5 0.48 0.75 3 25 KH-EZ( CRC) 1 / 2” x6” 1 / 2” 6 0.48 0.75 3 25 KH-EZ 5 / 8” x3 1 / 2” 5 / 8” 3 1 / 2 0.57 0.94 3 1 / 4 15 KH-EZ 5 / 8” x4” 5 / 8” 4 0.57 0.94 3 1 / 4 15 KH-EZ( CRC) 5 / 8” x5 1 / 2” 5 / 8” 5 1 / 2 0.57 0.94 3 1 / 4 15 KH-EZ( CRC) 5 / 8” x6 1 / 2” 5 / 8” 6 1 / 2 0.57 0.94 3 1 / 4 15 KH-EZ( CRC) 5 / 8” x8” 5 / 8” 8 0.57 0.94 3 1 / 4 15 KH-EZ 3 / 4 x4 1 / 2” 3 / 4” 4 1 / 2 0.70 1.13 4 10 KH-EZ( CRC) 3 / 4” x5 1 / 2” 3 / 4” 5 1 / 2 0.70 1.13 4 10 KH-EZ( CRC) 3 / 4” x7 3 / 4” 7 0.70 1.13 4 10 KH-EZ 3 / 4” x8” 3 / 4” 8 0.70 1.13 4 10 KH-EZ( CRC) 3 / 4” x9” 3 / 4” 9 0.70 1.13 4 10
Qty( pcs) / Box
80
