Table 4 — Hilti KH-EZ SS316 and KH-EZ C SS316 design strength with masonry failure modes in the face of uncracked fully grouted CMU walls and installed at minimum distance from centerline of hollow head joint 1 , 2 , 3 , 4
Nominal anchor diameter in .
1 / 4
3 / 8
1 / 2
Effective embedment in . ( mm ) f ́m = 1500 psi ( 10.3 MPa ) lb ( kN )
Tension ( lesser of breakout or pullout ) - ФN n
f ́m = 2000 psi ( 13.8 MPa ) lb ( kN ) f ́m = 2500 psi ( 17.2 MPa ) lb ( kN ) f ́m = 3000 psi ( 20.7 MPa ) lb ( kN )
Shear ( lesser of breakout , pryout , or crushing ) - ФV n
f ́m = 1500 psi ( 10.3 MPa ) lb ( kN ) f ́m = 2000 psi ( 13.8 MPa ) lb ( kN ) f ́m = 2500 psi ( 17.2 MPa ) lb ( kN ) f ́m = 3000 psi ( 20.7 MPa ) lb ( kN )
1.19 |
195 |
195 |
195 |
195 |
600 |
690 |
770 |
845 |
( 30 ) |
( 0.9 ) |
( 0.9 ) |
( 0.9 ) |
( 0.9 ) |
( 2.7 ) |
( 3.1 ) |
( 3.4 ) |
( 3.8 ) |
1.93 |
420 |
420 |
420 |
420 |
1,045 |
1,205 |
1,350 |
1,475 |
( 49 ) |
( 1.9 ) |
( 1.9 ) |
( 1.9 ) |
( 1.9 ) |
( 4.6 ) |
( 5.4 ) |
( 6.0 ) |
( 6.6 ) |
1.49 |
515 |
515 |
515 |
515 |
840 |
970 |
1,080 |
1,185 |
( 38 ) |
( 2.3 ) |
( 2.3 ) |
( 2.3 ) |
( 2.3 ) |
( 3.7 ) |
( 4.3 ) |
( 4.8 ) |
( 5.3 ) |
2.55 |
1,045 |
1,205 |
1,345 |
1,475 |
1,680 |
1,940 |
2,170 |
2,375 |
( 65 ) |
( 4.6 ) |
( 5.4 ) |
( 6.0 ) |
( 6.6 ) |
( 7.5 ) |
( 8.6 ) |
( 9.7 ) |
( 10.6 ) |
1.56 |
700 |
805 |
875 |
875 |
890 |
1,025 |
1,150 |
1,260 |
( 40 ) |
( 3.1 ) |
( 3.6 ) |
( 3.9 ) |
( 3.9 ) |
( 4.0 ) |
( 4.6 ) |
( 5.1 ) |
( 5.6 ) |
3.26 |
1,320 |
1,525 |
1,705 |
1,870 |
1,920 |
2,220 |
2,480 |
2,720 |
( 83 ) |
( 5.9 ) |
( 6.8 ) |
( 7.6 ) |
( 8.3 ) |
( 8.5 ) |
( 9.9 ) |
( 11.0 ) |
( 12.1 ) |
1 Linear interpolation between embedment depths and masonry compressive strengths is not permitted .
2 Tabular values are for a single anchor located 2.5-in from centerline of a hollow head joint with no additional influence from nearby edges or additional anchors . For designs with the influence of nearby edges , different distances to a hollow head joint , or additional anchors , use Hilti PROFIS Engineering Design software or perform anchor calculation using design equations from AC01 . 3 Compare masonry tabular values to the steel values in Table 8 . The lesser of the values is to be used for the design . 4 Tabular values are for static loads only . Seismic design is not permitted for uncracked masonry .
Table 5 — Hilti KH-EZ SS316 and KH-EZ C SS316 design strength with masonry failure modes in the face of cracked fully grouted CMU walls and installed at minimum distance from centerline of hollow head joint 1 , 2 , 3 , 4
Nominal anchor diameter in .
1 / 4
3 / 8
1 / 2
Effective embedment in . ( mm ) f ́m = 1500 psi ( 10.3 MPa ) lb ( kN )
Tension ( lesser of breakout or pullout ) - ФN n
f ́m = 2000 psi ( 13.8 MPa ) lb ( kN ) f ́m = 2500 psi ( 17.2 MPa ) lb ( kN ) f ́m = 3000 psi ( 20.7 MPa ) lb ( kN )
Shear ( lesser of breakout , pryout , or crushing ) - ФV n
f ́m = 1500 psi ( 10.3 MPa ) lb ( kN ) f ́m = 2000 psi ( 13.8 MPa ) lb ( kN ) f ́m = 2500 psi ( 17.2 MPa ) lb ( kN ) f ́m = 3000 psi ( 20.7 MPa ) lb ( kN )
1.19 |
90 |
90 |
90 |
90 |
420 |
490 |
545 |
595 |
( 30 ) |
( 0.4 ) |
( 0.4 ) |
( 0.4 ) |
( 0.4 ) |
( 1.9 ) |
( 2.2 ) |
( 2.4 ) |
( 2.6 ) |
1.93 |
185 |
185 |
185 |
185 |
735 |
850 |
950 |
1,045 |
( 49 ) |
( 0.8 ) |
( 0.8 ) |
( 0.8 ) |
( 0.8 ) |
( 3.3 ) |
( 3.8 ) |
( 4.2 ) |
( 4.6 ) |
1.49 |
210 |
210 |
210 |
210 |
590 |
685 |
765 |
835 |
( 38 ) |
( 0.9 ) |
( 0.9 ) |
( 0.9 ) |
( 0.9 ) |
( 2.6 ) |
( 3.0 ) |
( 3.4 ) |
( 3.7 ) |
2.55 |
735 |
770 |
770 |
770 |
1,200 |
1,385 |
1,550 |
1,695 |
( 65 ) |
( 3.3 ) |
( 3.4 ) |
( 3.4 ) |
( 3.4 ) |
( 5.3 ) |
( 6.2 ) |
( 6.9 ) |
( 7.5 ) |
1.56 |
495 |
570 |
635 |
690 |
630 |
725 |
810 |
890 |
( 40 ) |
( 2.2 ) |
( 2.5 ) |
( 2.8 ) |
( 3.1 ) |
( 2.8 ) |
( 3.2 ) |
( 3.6 ) |
( 4.0 ) |
3.26 |
935 |
1,075 |
1,205 |
1,320 |
1,375 |
1,585 |
1,775 |
1,940 |
( 83 ) |
( 4.2 ) |
( 4.8 ) |
( 5.4 ) |
( 5.9 ) |
( 6.1 ) |
( 7.1 ) |
( 7.9 ) |
( 8.6 ) |
1 Linear interpolation between embedment depths and masonry compressive strengths is not permitted .
2 Tabular values are for a single anchor located 2.5-in from centerline of a hollow head joint with no additional influence from nearby edges or additional anchors . For designs with the influence of nearby edges , different distances to a hollow head joint , or additional anchors , use Hilti PROFIS Engineering Design software or perform anchor calculation using design equations from AC01 . 3 Compare masonry tabular values to the steel values in Table 8 . The lesser of the values is to be used for the design . 4 Tabular values are for static loads only . For seismic loads , multiply design strength values in tension and shear by the following reduction factors : 1 / 4-in diameter = 0.70 3 / 8-in and 1 / 2-in diameters = 0.75
