also taking into account losses due to spillage, leakage, catchment surface wetting, and
evaporation (Singh, 1992).
b. Rainwater quality
The quality of rainwater run-off from a catchment surface can be affected in two ways. Dirt and
debris can collect on the roof surface from direct atmospheric deposition, from overhanging
foliage or bird and rodent droppings. Alternatively, the roof material itself can contribute both
particulate matter and dissolved chemicals to run-off water.
CONVEYANCE SYSTEM
Rainfall collected by the catchment is transferred to the rainwater storage tank through the
conveyance network (Figure 4.4).
Figure 4.4: A typical conveyance
network for an above ground rainwater
storage tank.
Rooftop rainwater harvesting conveyance systems consist of two basic elements:
1. gutter(s) that collect water from the roof; and
2. downspout(s) that channel the water collected by the gutters into the storage tank.
DESIGN AND INSTALLATION OF CATCHMENT AREA AND CONVEYANCE NETWORK
Selection of the catchment area
• Only roof surfaces are recommended;
• Ensure that your rooftop is suitable for RWH. Corrugated iron or metal rooftops are best for
harvesting rainwater, followed by tiled and concrete rooftops. Thatched roofs, green roofs
or any roof painted with paint-releasing chemicals are not suitable for practical rainwater
harvesting; and
• Sections of the roof with overhanging foliage or trim where possible should be avoided as
much as possible.
To maximise the volume of rainwater collected by the RWH system
• The catchment surface should be as large as possible;
• When a roof catchment material can be selected and installed in conjunction with
the RWH system, material with run-off coefficient close to 1, such as steel, should
be selected to convey rainwater using appropriately sized and sloped components,
including gutters, downspouts, and/or conveyance drainage piping; and
• where possible, combine the surface area of several multiple roof catchments and connect
them to a central rainwater storage tank.
