DESIGN: DEAR MR PLUMBER 21 Notes on a drawing: Part 1 By Vollie Brink In the past, I have been asked to review the design drawings of other, shall I just say ‘designers’, and to comment on the design. When I review the drawings of other people then it is important, not to see if it complies with my view, but if it complies with the regulations. This is Part 1 of a two-part series. The regulations as stated in the National Building Regulations (NBR), which you will find in the relevant Addendums, and which are the most important part of the NBR, describe ‘how the system must perform’, and it is basically the specifications for the designed and constructed system. However, it is extremely important that these specifications for the performance be clearly built into the design and the design must comply with the agreement with the owner / developer, which in most cases is the PROCSA agreement, which stipulate all the phases of design and construction in detail. Any design must comprise of detailed drawings and ‘specific detailed specifications’ – and this is where I find problems. Many ‘designers’ cover themselves by means of ‘notes’ on the drawings, such as: ‘The drainage system shall comply with SANS 10400-P’ or ‘The domestic water system shall comply with SANS 10252-1’. However, SANS 10400-P and SANS 10252-1 consist of many options, raising the question of which option the plumber must comply with? I encountered someone who had just indicated by means of a note that the gradient must be 1:60 and the actual gradient installed was 1:1000 and the reason for it was that the space in the building only allowed this 1:1000 gradient. This meant that the designer did not actually check if the pipe can be installed as per the ‘note’ on the drawing. If an appropriate Quality Assurance (QA) system was applied, then the abovementioned problem should have been found and rectified before the building was occupied. However, the problem should have been found earlier by means of a ‘Design QA’ system by the designer. It seems the designer and the plumber lack training in QA. SANS 10252-1 is inherently a Design Manual with some installation rules. If the designer puts a ‘note’ on the drawing that the installation must comply with this document, does that mean the plumber must do the design? In the case of this document we deliberately designed the tables with ‘ranges’ of ‘flow rates’ and ‘volumes’ and pressures, and more. Vollie Brink is one of the industry’s longest-serving wet services engineers. He continues to serve on SABS committees and has been involved in the Green Building Council’s Green Star rating system. Brink continues to consult for various organisations while enjoying a well- earned retirement. These ‘ranges’ were devised so as to force the designer to select a flow rate and pressure and volume to suit the specific project. We also deliberately used litres per minute and not litres per second because litres per minute is full figures and not figures with decimals and easier to calculate without a calculator. PA There is a Table for gradients for discharge pipes inside buildings and there is a Table for drains which must connect the building with the municipal sewer. These gradients of the piping inside and outside the buildings must be carefully calculated to convey the effluent from the fixtures in the building, through the building, through the drains outside the building up to the sewer connection and even further down to the sewage treatment plant, which as mostly kilometres away from the property, and if there is not enough gradient and water the municipal system cannot function. By the way, all the Tables for sizing of the piping and gradients in SANS 10400-P and SANS 10252-2, are ‘wrong’. All the invert levels, gradients, dimensions and access positions must all be correctly indicated on the design drawings, and you cannot get away with a note. March 2020 Volume 26 I Number 01 You cannot get away with a ‘note’ on the drawing that all pipes must have a fall of 1 in 60. You must calculate and indicate the exact positions and exact invert levels on the drawings and it must relate to the levels of the building or to a peg on the site with a specific level. In one instance www.plumbingafrica.co.za
