PROJECT 25
Supplier Product Description Bio Zone
The Bio Zone filtration plant. HMS Pumps
Dual Vertical Stainless steel Multistage Booster pumps.
Large-scale filtration system( designed specifically for the project)
Water booster pumps( designed specifically for the project)
1.5kW Ebara CDX x 1 Rota meter 5m 3 x 1 16 x 65 Vessel x 2 Auto backwash head x 2 Riser pipe x 2 Top distributor x 2 Bottom distributor x 2 2m 3 UV steriliser x 1 AFM Gr 1 x 4 AFM Gr 2 x 2 AFM Gr 3 x 3 Ph Fix x 6 Double length bag filter x 1 Skid with shelter x 1 Electrical control panel x 1 Sodium hypo dosing tank and pump x 1 Sodium hypo 25 Lt x 1 Water meter x 1
JoJo Tanks Water storage tanks 6 x 5 250l JoJo tanks
Dual MVDL4120 / 22 Vertical Stainless steel Multistage Booster pumps:
• 2 off Frecon 2.2kw 230 / 380 Full function Variable Speed Drives including surge / overload motor protection, including Dry run and auto restart
• 4-20Ma Pressure transducers 16 bar and 1200kpa Pressure gauge
• 100l vertical pressure sustaining tank with braided hose and fittings
• 50mm x 32mm Galvanised Suction manifold
• 40mm x 32mm Galvanised Discharge manifold
• Intermediate Galvanised fittings and piping
• 2 sets required isolating and non return valves
• Main control panel with selector switches, main isolator and required relays
• Base mounted panel frame in mild steel
BMT( Bull Morris) |
Valves |
Non-return valves, shut-off valves and |
|
|
backflow prevention valves |
Astore Piping uPVC piping
Two tanks for the borehole, four tanks for the purification and backup water supply( a total of six tanks).
