Plastec Catalogue 2014 March 2014

TWIST TOP SYSTEMS LEAK CONTROL SYSTEMS RECESSED - SOLVENT WELD ROUND BRASS SLOTTED GRATE ID OUTLET NOTES • Grate can screw down level with ﬂange height • Ideal for thin le beds • Adjust height by twis ng threaded adapter • Addi onal reba ng required for shoulder of ﬂange GRATE 12270 80 x 50 SPIGOT CHROME 30 12271 80 x 80 SPIGOT CHROME 35 12273 100 x 80 SPIGOT CHROME 30 12274 100 x100 SPIGOT CHROME 24 12272 100 X 50 CHROME 25 SOCKET SQUARE BRASS SLOTTED GRATE ID OUTLET GRATE 14918 80 x 50 SPIGOT CHROME 30 14919 80 x 80 SPIGOT CHROME 40 16759 100 x 50 SOCKET CHROME 16758 100 x 80 SPIGOT CHROME 30 15229 100 x100 SPIGOT CHROME 25 25 NOTES • Grate can screw down level with ﬂange height • Ideal for thin le beds • Adjust height by twis ng threaded adapter • Addi onal reba ng required for shoulder of ﬂange ROUND STAINLESS STEEL GRATE ID OUTLET GRATE 12260 30 S/STEEL 35 100 x 80 SPIGOT S/STEEL 30 100 x100 SPIGOT S/STEEL 25 12262 BAG QTY S/STEEL SPIGOT 12264 FASTENING SPIGOT 80 x 80 12263 DIAMETER 80 x 50 12261 100 x 50 S/STEEL 25 CARTON QTY SOCKET FINISH/COLOUR NOTES • Pressed stainless steel grate • Grate can screw down level with ﬂange height • Ideal for thin le beds • Adjust height by twis ng threaded adapter • Addi onal reba ng required for shoulder of ﬂange MEASUREMENT MM H.11

Plastec Catalogue 2014 March 2014 | Page 141
