Backhoe Excavators Drills Top Hammer Boom Drills Make Sandvik Sandvik Sandvik Sandvik Model DX800 DP1100i DP1500i DX900i Recommended hole diameter (mm) 76 - 127 89 - 140 89 - 150 89 - 140 Drill Rod diameters (mm) 45 / 51 51 / 60 51 / 60 rods, 76 / 87 tubes 51 / 60 Hydraulic rock drill HL820T HL1060T HL1560T RD927L, RD927L-C Percussion output power (kW) 23 25 33 27 Engine type C7.1 Tier 3 & Tier 4 C9 Tier 3, C9.3 Tier 4 C11 Tier 3, C13 Tier 4 Volvo TAD852VE Engine output power (kW @ rpm) 168 @ 1800 225 @ 1800 261 @ 1800 210 @ 1800 Flushing air capacity (m3/minute) 8,1 up to 10 bar 14 up to 10 bar 14, up to 10 bar 9.5 up to 10 bar Operators cabin Ergo Ergo Cool Ergo Cool iCab Certificate ROPS & FOPS ROPS & FOPS ROPS & FOPS ROPS & FOPS South African distributor Sandvik Sandvik Sandvik Sandvik High-power DTH Drills Make Furukawa Soilmec Soilmec Model DC22 SM-14 SM-22 Hole diameter (mm) 127 - 171 50 - 415 50 - 315 Drill pipe length (m) 5 / 6 65 90 Drill pipe diameter, standard 4 rods, carousel loader (mm) 6 / 114 89 - 114 114 - 180 Drill pipe diameter, optional 8 rods, carousel loader (mm) 5 / 102 76 - 89 76 - 114 Depth capacity without reloading (Standard 4 rods) (m) 25 18 54 Depth capacity without reloading (Optional 8 rods) (m) 40 24 72 - Extendable crawlers with outriggers Extendable crawlers with outriggers Air delivery @ 1 800 rpm (m 3 /minute @ bar) - Hydraulic Hydraulic Air delivery @ 2 100 rpm (m /minute @ bar) 24,3 - 27 Hydraulic Hydraulic Engine Power (kW @ rpm) 328 @ 2200 119 @ 2200 194 @ 2000 Distributor ELB Equipment Pilequip SA Pilquip SA Undercarriage 3 Top Hammer Drills Make Furukawa Soilmec Soilmec Soilmec Model HCR 1800 ED SM-5 SM-6 SM-9 Recommended hole diameter (mm) 102 - 152 30 - 150 30 - 220 50 - 320 Drill Rod diameters (mm) GT60 / T60 28, 32, 45, 51, 76 28, 32, 45, 51, 76, 89 28, 32, 45, 51, 72, 76, 89, 114 Hydraulic rock drill HD836 Eurodrill RH4X Eurodrill RH4X Eurodrill RH21X Percussion output power (kW) 36 15 15 28 Engine type CAT C9 DEUTZ TCD 2011 L04W DEUTZ TCD3.6 L04W DEUTZ TCD4.1 L04W Engine output power (kW @ rpm) 261 @ 2200 71,2 @ 2300 100 @ 2000 105 @ 2000 Flushing air capacity (m3/minute) 14,2 Hydraulic Hydraulic Hydraulic Operators cabin - No Cabin No Cabin No Cabin Control - Remote control or manual Remote control or manual Remote control or manual Certificate Rops/Fops - - - Distributor ELB Equipment Pilequip SA Pilequip SA Pilequip SA www.equipmentandhire.co.za DECEMBER 2019 97
