Plant Equipment and Hire Equipment Specs Handbook 2020 | Page 64

Make
ASC 100
Ammann
Ammann
ASC 120
Ammann
ASC 150
Ammann
ASC170
ASC200
Ammann
Model
62
Pad Foot
Rollers
Ammann Ammann
ASC 250 ASC 110 ACE
Pro
Operating weight (kg) 10120 11430 15500 - 18500 16270 21000 - 26000 25500 11490
Type Smooth drum/
PD shell Smooth drum/
PD shell Smooth drum/
PD shell Smooth drum/
PD shell Smooth drum/
PD shell Smooth drum/
PD shell S/D smart
compaction
Drum width (mm) 2130 2130 2130 2130 2240 2240 2130
Number of pads - - - - - - -
Pad area (cm 2 ) - - - - - - -
Nominal amplitude 1,85 / 1,15 1,85 / 1,15 42036 2,2 / 1,1 - 2,2 / 1,1 Variable
amplitude
Vibration frequency (Hz) 32 / 35 32 / 35 29 / 35 28 / 35 28 / 34 28 / 34 Variable
frequency
Centrifugal force High/low amp (kN) 277 / 206 277 / 206 325 / 236 335 / 260 400 / 300 460 / 340 Variable kN
Make Cummins Cummins Cummins Cummins Cummins Cummins Cummins
Model 4 BTA 3.9-C116 4 BTA 3.9-C116 QSB 4.5-C160 QSB 4.5-C160 QSB6,7-C220 QSB6,7-C220 QSB 3.3-C99
Net power (kW @ rpm) 87 86 @ 2200 119 @ 2200 119 @ 2200 164 @ 2200 164 @ 2200 86 @ 2200
Length (mm) 5630 5630 5900 5900 6300 6300 5780
Width (mm) 2250 2250 2258 2258 2500 2500 2258
Height (mm) 3027 3027 3075 3075 3265 3265 3070
Turning circle radius (mm) - - - - - - -
South African distributor ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment ELB Equipment
Make Ammann Bomag Bomag Dynapac Dynapac Dynapac Dynapac Dynapac
Model ARS 122 BW 212
PD-40 BW 219 PD-4 CA1500PD CA250PD CA270PD CA2800PD CA300PD
Operating weight (kg) 11200 -
13180 13320 19360 7500 11600 13300 13900 14600
Type Smooth drum/
PD shell Single Drum
Roller Single Drum
Roller Padfoot Padfoot Padfoot Padfoot Padfoot
Drum width (mm) 2130 2130 2130 1676 2130 2130 2130 2130
Number of pads - 150 150 132 130 150 150 150
Pad area (cm 2 ) - 137 137 84 146 146 146 146
Nominal amplitude 1,85 / 1,15 1,7 / 0,86 1,8 6/ 1 1,7 / 0,9 1,6 / 0,8 1,7 / 0,8 1,7 / 0,8 1,7 / 0,8
Vibration frequency (Hz) 32 / 35 30 / 36 26 / 31 31 / 43 33 / 33 33 / 33 33 / 33 33 / 33
Centrifugal force High/low amp (kN) 277 / 206 275 / 202 314 / 240 143 / 136 300 / 146 248 / 121 246 / 119 300 / 146
Make Cummins Deutz Deutz Cummins Cummins Cummins Cummins Cummins
Model 4 BTA 3.9-
C99 BF4M 2012 C TCD 2012
L06 QSB3.3 4BTA3.9 4BTA3.9 4BTA3.9C QSB 6.7
Net power (kW @ rpm) 74 @ 2200 98 @ 2300 150 @ 2200 60(80) 82(110) 76(102) 82(110) 112(150)
Length (mm) 5460 5840 6338 4871 5550 5550 5550 5758
Width (mm) 2260 2250 2300 1852 2344 2384 2344 2384
2977 Height (mm) 3030 2985 3022 2867 2977
Turning circle radius (mm) - 3494 3890 2770 -
South African distributor ELB
Equipment Bell
Equipment Bell
Equipment Dynapac Dynapac
DECEMBER 2019
Dynapac
2952 2996
- -
Dynapac Dynapac
