Backhoe Excavators Mobile Screens Make Kleemann Kleemann Kleemann Kleemann Kleemann Kleemann Kleemann Model MS 13 Z-AD MS 14 Z MS 15 Z-AD MS 16 Z MS 16 D MS 19 Z MS 19 D Operating mass (kg) 23000 19500 34000 27000 29000 36000 36500 Type Double Deck Double Deck Double deck Double deck Triple deck Double deck Triple deck Top deck (m) 1370 x 3660 1370 x 3050 1520 x 4880 1520 x 4270 1520 x 4270 1520 x 6100 1520 x 6100 Bottom deck (m) 6 6 8 8 8 8 8 Production (t/hour max) 300 250 400 350 350 500 500 Make Cat Cat Cat Cat Cat Cat Cat Model 4.4 4.4 4.4 4.4 4.4 4.4 4.4 Power (kW @ rpm) 75 @ 2200 75 @ 2200 95 @ 2200 75 @ 2200 75 @ 2200 95 @ 2200 95 @ 2200 Height (mm) 3200 3200 3400 3400 3450 3400 3450 Length (mm) 12780 13210 15330 15420 15610 17820 17600 Width (mm) 2500 2500 2900 3000 3000 3000 3060 South African distributor Wirtgen South Africa Wirtgen South Africa Wirtgen South Africa Wirtgen South Africa Wirtgen South Africa Wirtgen South Africa Wirtgen South Africa Make Kleemann Kleemann Kleemann McCloskey McCloskey McCloskey McCloskey McCloskey Model MS 21 Z-AD MS 20 D MS 23 D S130 2-Deck S190 2-Deck S250 2-Deck R155 2-Deck R230 2-Deck Operating mass (kg) 40000 57000 85000 27200 36500 42430 29860 37200 Type Double deck Triple deck Triple deck Vibrating Screen Vibrating Screen Vibrating Screen Scalping Screen Scalping Screen Top deck (m) 1830 x 6100 2050 x 6000 2300 x 8000 4270 x 1524 6100 x 1524 6710 x 1830 4880 x 1525 6100 x 1830 Bottom deck (m) 11,5 - - N/A N/A N/A N/A N/A Production (t/hour max) 500 650 800 - - - - - Make Cat Scania Scania Cat Cat Cat Cat Cat Model 6.6 DC 9 DC 9 4.4 TIER 3 4.4 TIER 3 C7.1 TIER 3 C4.4 TIER 3 C6.6 TIER 3 Power (kW @ rpm) 168 @ 2200 226 @ 1500 226 @ 1500 97 @ 2200 97 @ 2200 209 @ 2200 94 @ 2200 168 @ 2200 Height (mm) 3500 3900 3400 3400 3600 3400 3500 Length (mm) 16760 18500 15610 17540 18630 15300 16970 Width (mm) 3000 3450 Transport in sections 2900 2900 3660 2900 3000 South African distributor Wirtgen South Africa Wirtgen South Africa Wirtgen South Africa HPE Africa HPE Africa HPE Africa HPE Africa HPE Africa Transport in sections Transport in sections Make Metso Metso Metso Metso Metso Pilot Crushtec Powerscreen Model ST3.5 ST3.8 ST4.8 ST620 ST2.8 DynamiTrac TDH6118 Warrior 600 Operating mass (kg) 23000 28000 32000 30500 26000 48000 12000 2 deck Type 2 Deck 2 Deck 3 Deck 3 Deck 2 Deck Scalping 3 Deck horizontal screen Top deck (m) 3580 x 1524 5480 x 1524 5480 x 1524 6000 x 1800 4866 x 1524 6100 x 1800 2340 x 1170 Bottom deck (m) 3580 x 1524 5480 x 1524 5480 x 1524 6000 x 1800 4867 x 1524 6100 x 1800 2340 x 1170 Production (t/hour max) Up 300 Up to 400 Up to 400 Up to 500 750 up to 600 Up to 280 Volvo Deutz Make Cat Cat Cat Cat Cat - Bi Power Option Model C 4.4 C 4.4 C 4.4 C 7.1 C 4.4 TAD542VE 2011 Power (kW @ rpm) 75 75 75 130 75 160 36,4 @ 2300 Height (mm) 3460 3420 3630 3800 3560 3574 2550 Length (mm) 14350 18300 18320 14900 15400 19372 10980 Width (mm) 3000 3190 3190 3000 3000 3000 2250 South African distributor Pilot Crushtec International Pilot Crushtec International Pilot Crushtec International Pilot Crushtec International Pilot Crushtec International Pilot Crushtec International ELB Equipment www.equipmentandhire.co.za DECEMBER 2019 59
