LISA LARGE SCIENTIFIC PROJECT
LISA payload critical technologies
The LISA mission relies on several tightly integrated, high-performance technologies that enable the detection of GWs in the mHz frequency band, with a required noise floor below 10 pm / √Hz. The main technologies- shown in Fig. 3 and described below- push the limits of current space optics and engineering, and must operate with exceptional stability and reliability throughout the extended mission lifetime of ten years. A core technology of LISA is the realization of near-perfect free-fall TMs, which serve as inertial references and act as a mirror for the laser beam. Each S / C houses at the end of the arm a cubic gold – platinum TM( ≈2 kg, 46 mm side length), selected for its extremely low magnetic susceptibility and thermal sensitivity. Non-gravitational forces must be reduced so that residual acceleration noise stays below ~ 3 × 10 – 15 m · s – 2 / √Hz above 0.1 mHz. This requires tight control of electrostatic forces( few fN / √Hz), magnetic and thermal fluctuations( few nT / √Hz and < 10 μK / √Hz), and of TM charge(< ~ 10⁷ e-). The surrounding Gravitational Reference Sensor( GRS) provides capacitive sensing and electrostatic actuation with < ~ 1 nm / √Hz, displacement noise in ultra-high vacuum(< 10 – 5 Pa), enabling near-ideal free fall as demonstrated by LISA Pathfinder. Ultra-high-precision laser interferometry is at the heart of LISA’ s measurement system. The mission uses single-frequency, continuous-wave Nd: YAG lasers at 1064.5 nm delivering ~ 2 W, and MHzbeat-note heterodyne interferometry achieves phase readout noise below ~ 10 μrad / √Hz, corresponding to ~ 1 – 2 pm displacement resolution. Despite pre-stabilization to an ultra-stable cavity(~ 30 Hz / √Hz in the mHz band), laser frequency noise still dominates because of the ~ 8 s light-travel time over the 2.5 million km arms. Time Delay Interferometry( TDI) suppresses this noise by 8 – 9 orders of magnitude by combining time-shifted phase measurements from the three spacecraft to synthesize virtual equalarm interferometers, pushing laser noise well below TM acceleration noise and shot noise across the LISA band. The optical bench is a central, performance-critical element of the interferometric system, providing a mechanically and thermally ultra-stable platform for measurement. Built as a quasi-monolithic structure from ultra-low-expansion glass-ceramic with optics bonded by hydroxide-catalysis, it offers sub-nanometer long-term stability. Optical pathlength noise must remain below a few pm / √Hz, requiring strict control of thermal gradients, mechanical stress, and alignment. LISA telescopes are key optical subsystems that transmit and receive the laser beams between S / C while preserving wavefront quality and pointing stability. Each telescope has an aperture of 30 cm and must deliver diffraction-limited performance with extremely low wavefront distortion. Pointing jitter and pathlength fluctuations must remain of ~ few nrad / √Hz and ~ 1 pm / √Hz to avoid degrading the interferometric phase measurement. Maintaining the TM in free fall requires drag-free control of the spacecraft, implemented using ultra-low-noise micro propulsion systems. Microthrusters provide continuous thrust at the level of a few µ N to counteract non-gravitational forces such as solar radiation pressure, while maintaining thrust noise below a few tens of nN / √Hz in the LISA measurement band. This performance is essential to prevent S / C motion without reintroducing acceleration noise onto the TMs. Control of stray light is another key technology challenge for LISA. Scattered, reflected, or back-coupled light – whether in fibers or free-space – can coherently mix with the main interferometric signals and generate spurious phase noise. Stray-light-induced heterodyne noise must remain at ~ 1 pm / √Hz in each interferometer. Achieving this requires careful optical design, dedicated baffles and beam dumps, low-scatter optical coatings, tight control of surface roughness, and accurate knowledge of component-level scattering. Complex optical simulation, including imperfections, and dedicated monitoring equipment’ s are essential to identify, quantify, and mitigate coherent stray light.
