ZILLON
®
Adjustable work positioning
lanyard for tree care
NEW
2015
MOBILE FALL
ARRESTERS
LANYARDS
ENERGY
ABSORBERS
Easily adjusted with one hand thanks to
the progressive locking/unlocking action
of the device.
HELMETS
HARNESSES
Positioning lanyard for tree care
(1) The IGUANE helivac lanyard does not have an
energy absorber. It should thus only be used if the fall
factor is less than 1 (used below the anchor point).
DESCENDERS
ROPE CLAMPS
PULLEYS
• Designed for ground helivac:
- on the metal frame, a large upper hole for rapid
attachment of the helicopter winch
- double lower end allowing the rescuer and victim to
be connected
- carabiner fixed to the metal frame to attach a litter
• Easy manipulation:
- instant identification of the attachment elements
thanks to their color coding
- facilitated clipping due to connectors held in correct
position
• Dynamic rope lanyard to limit the impact transmitted
to the user in case of a short fall (1)
• Lanyard developed in partnership with the Peloton de
Gendarmerie de Haute Montagne de Chamonix MontBlanc (France)
• Weight: 600 g
• Certification(s): CE
ANCHORS
ROPES
Helivac lanyard for ground drop off/
recovery
• It is used doubled, on the harness side
attachment points, to distribute the load on the
waistbelt
• Easily adjusted with one hand thanks to the
progressive locking/unlocking action of the device
• Pulley mounted on sealed ball bearings to allow
slack to be taken up easily
• Steel friction elements for increased longevity
• Available in three lengths:
- ZILLON 25 (L22 025): 2,5 m (605 g)
- ZILLON 40 (L22 040): 4 m (790 g)
- ZILLON 55 (L22 055): 5,5 m (975 g)
• Replacement ropes available in different sizes:
- 2,5 m (L22R 025)
- 4 m (L22R 040)
- 5.5 m (L22R 055)
• Certification(s): CE EN 358
PACKS
ACCESSORIES
IGUANE L01G
CONNECTORS
Pulley mounted on sealed ball bearings
allows slack to be taken up easily.
