ABSORBICA-Y MGO 150
ABSORBICA-Y MGO 80
ABSORBICA-Y 150
ABSORBICA-Y 80
ABSORBICA-I MGO 150
ABSORBICA-I MGO 80
ABSORBICA-I 150
Lanyards with energy absorber
ABSORBICA-I 80
74
ABSORBICA-I
ABSORBICA-Y
Energy absorber with integrated single lanyard
Energy absorber with integrated double lanyard
• Designed for protection on a horizontal lifeline (rope or cable)
• The energy of the fall is absorbed by the tearing of specific webbing
• Mesh pouch with zipper protects the energy absorber from abrasion or
spray and allows regular inspection of the absorber's condition
• Energy absorber end equipped with STRING
• Available without connector or with MGO large-opening connector, so in two
lengths:
- ABSORBICA-I 80 (L58): 0.8 m not including connector (1.5 m after tearing),
160 g, maximum clearance (factor 2 fall): 4.35 m
- ABSORBICA-I 80 MGO (L58 MGO): 1.05 m (1.75 m after tearing), 655 g,
maximum clearance (factor 2 fall): 4.35 m
- ABSORBICA-I 150 (L70150 I): 1.5 m not including connector (3.35 m after
tearing), 365 g, maximum clearance (factor 2 fall): 6.1 m
- ABSORBICA-I 150 MGO (L70150 IM): 1.75 m (3.6 m after tearing), 825 g,
maximum clearance (factor 2 fall): 6.1 m
• Certification(s):
- ABSORBICA-I 80 and 150: CE EN 355, EAC
- ABSORBICA-I 80 MGO and 150 MGO: CE EN 355, CE EN 362, EAC
• Designed for continuous protection while passing intermediate anchors
• The energy of the fall is absorbed by the tearing of specific webbing
• Mesh pouch with zipper protects the energy absorber from abrasion or
spray and allows regular inspection of the absorber's condition
• Energy absorber end equipped with STRING
• Available without connector or with MGO large-opening connector, so in two
lengths:
- ABSORBICA-Y 80 (L59): 0.8 m not including connector (1.5 m after tearing),
210 g, maximum clearance (factor 2 fall): 4.35 m
- ABSORBICA-Y 80 MGO (L59 MGO): 1.05 m (1.75 m after tearing), 1120 g,
maximum clearance (factor 2 fall): 4.35 m
- ABSORBICA-Y 150 (L70150 Y): 1.5 m not including connector (3.35 m after
tearing), 500 g, maximum clearance (factor 2 fall): 6.1 m
- ABSORBICA-Y 150 MGO (L70150 YM): 1.75 m (3.6 m after tearing),
1420 g, maximum clearance (factor 2 fall): 6.1 m
• Certification(s):
- ABSORBICA-Y 80 and 150: CE EN 355, EAC
- ABSORBICA-Y 80 MGO and 150 MGO: CE EN 355, CE EN 362, EAC
Fall arrest and clearance distance, see page 5
