58
Rescue litter
Evacuation triangles
The NEST litter was developed in partnership with the French national caving rescue organization. It
is therefore ideal for all technical rope rescue, particularly in confined spaces.
Evacuation triangles are mainly used for rescue, on
ski lifts and by firefighters. They are used to evacuate
unequipped people as quickly as possible.
STEF
PITAGOR
NEST
BERMUDE
NEST S61
STEF S59
PITAGOR C80 BR
Litter for confined spaces
Tilting device for NEST litter
• Allows the victim to be transported
horizontally, vertically or at an angle, to adapt
to irregular or narrow terrain
• Litter has a complete body harness
integrated in it to secure the victim. Color
coded to avoid any installation error
• DoubleBack self-locking buckles for quick,
easy adjustment
• Smooth, rigid plastic bottom ensures good
sliding
• Foam padding provides comfort for the
victim's back
• Rigid stays can be removed to reduce bulk
during access
• Optional accessory: STEF inclination device
allows the litter to be easily tilted according to
the terrain
• Weight: 12.8 kg
• Dimensions: 200 x 50 x 5 cm
• Allows the litter to be easily tilted according
to the terrain
• TRIACT-LOCK directional connectors
automatically lock the three connection points
• Swivel allows the litter to be precisely
oriented
• SPIRIT carabiner integrated for fixing the litter
in horizontal position
• Weight: 600 g
Evacuation triangle with shoulder
straps
• Shoulder straps make it easy to put on
• Adjusts quickly and easily on the victim with selflocking DoubleBack buckles
• Certification(s): CE EN 1497, EN 1498
• Weight: 1290 g
BERMUDE C80
Evacuation triangle without
shoulder straps
• Easy and quick to put on (even on a sitting person)
• Adapts to different builds without adjustment
(many position options on attachment points)
• Certification(s): EN 1498
• Weight: 795 g
