110
Haul kit
JAG SYSTEM P44
Haul kit
NEW
2015
Am’D TRIACT-LOCK automatic locking
carabiner
JAG TRAXION high efficiency double
progress capture pulley
8 mm lightweight rope
8 ≤ ø ≤ 11 mm
Flexible cover prevents any risk of
tangling
JAG TRAXION
NEW
2015
JAG high-efficiency double pulley
Am’D TRIACT-LOCK automatic locking
carabiner
• Versatile:
- allows pickoffs, making a releasable anchor,
tensioning a system...
- can be coupled with an I'D descender to make a
reversible rescue kit to pickoff and evacuate a victim
• Hauling effectiveness:
- 4:1 mechanical advantage allows user effort to be
divided by 4
- excellent efficiency due to sheaves mounted on
sealed ball bearings
- deployment possible even when the distance
to the anchor is very short, thanks to the extreme
compactness of the collapsed system (30 cm)
- 8 mm lightweight rope. The mechanical advantage
guarantees a good grip
• Quick and easy to deploy:
- kit always ready to use thanks to the flexible cover
that prevents any risk of tangling
- haul end immediately identifiable thanks to the
yellow color of the end of the cover
- the ends of the cover hold the connectors in
position to facilitate clipping
• Comes with two Am'D TRIACT-LOCK auto-locking
carabiners
• JAG and JAG TRAX ION pulleys also available
separately for making long haul systems (e.g.
confined space descent/ascent system)
• Working load limit: 6 kN
• Breaking strength: 16 kN
• Weight: 590 g
8 ≤ ø ≤ 11 mm
JAG
JAG TRAXION P54
High efficiency double progress
capture pulley
The kit is always ready to use, thanks to
the flexible cover that prevents any risk
of tangling
• Designed for use with the JAG double pulley to
make a 4:1 haul system
• Toothed cam with self-cleaning slot optimizes
performance under any conditions (frozen or
muddy ropes...)
• Sheaves mounted on sealed ball bearings for
excellent efficiency
• Sheave diameter: 25 mm
• Efficiency: 91 %
• Working load limit: 2 × 1.5 kN × 2 = 6 kN
• Weight: 145 g
• Certification(s): CE EN 567, NFPA 1983 Technical
Use
JAG P45
High-efficiency double pulley
30 cm
The JAG SYSTEM is very compact,
allowing use even when the distance to
the anchor is very short
• Designed for use with the JAG TRAXION double
progress capture pulley to make a 4:1 haul system
• Sheaves mounted on sealed ball bearings for
excellent efficiency
• Sheave diameter: 25 mm
• Efficiency: 91 %
• Working load limit: 2 × 1.5 kN × 2 = 6 kN
• Weight: 120 g
• Certification(s): CE EN 12278, NFPA 1983
Technical Use
