106
Progress capture pulleys
PRO TRAXION P51A
Very efficient loss-resistant progress capture pulley
Locking button for cam
Attachment hole
Toothed cam
Pulley safety catch (visual indicator when
unlocked)
Connection point for hauling
8 ≤ ø ≤ 13 mm
8 ≤ ø ≤ 11 mm
• Progress capture pulley designed to make it as
simple as possible to install
- the rope can be easily installed when the pulley
is connected to the anchor
- the pulley always stays attached to its
connector, making it loss-proof
• Well suited for hauling heavy loads:
- large diameter sheave mounted on sealed ball
bearings for excellent efficiency
- side plate locks when loaded and prevents
opening of the pulley during use
• Versatile:
- lower connection point for creating different
types of hauling systems
- toothed cam with self-cleaning slot optimizes
performance under any conditions (frozen or dirty
ropes...)
- may be used as simple pulley by locking the
cam in the raised position
MICRO TRAXION P53
Very efficient, ultra-compact
progress capture pulley
• Ultra-compact and lightweight
• Versatile:
- toothed cam with self-cleaning slot optimizes
performance under any conditions (frozen or dirty
ropes...)
- may be used as simple pulley by locking the cam
in the raised position
• Aluminum sheave mounted on sealed ball
bearings for excellent efficiency
The rope may be installed in the PRO
TRAXION pulley when the pulley is
connected to the anchor.
