INDIVIDUAL CONFIGURATION
PANEL PC P15RL01
2 × 2.5 GBIT FANLESS
ALUMINIUM IP65 9-36 VOLT MULTI TOUCH
MODERN PANEL PCS FOR INDUSTRIAL APPLICATIONS
High-performance, highly integrated panel PC solutions featuring capacitive widescreen multitouch, a robust 3 mm aluminium chassis and an IP65-rated front panel. All models feature fanless operation and can be configured to meet specific industrial requirements. Each system is available in two colours.
More information: WWW. SHUTTLE. EU
TIP: A panel PC tailored to your project! Use our product configurator to customise your system to meet your requirements. go. shuttle. eu / RuDLM
• 15.6 inch( 39.6 cm), Full HD
• 10-point capacitive multitouch
• Intel Core i5-1335U
• Up to 64 GB DDR5 SO-DIMM
• 1 × M. 2 slot( 2280 / 2242) for NVMe or SATA SSD
• 2 × 2.5G LAN, Wi-Fi 5( 802.11ac)
• 2 × HDMI 2.0b, 8 × USB, 1 × COM; VGA optional
• 9 – 36 V DC input( optional, requires VOL01)
• Also available as M15AL01 in white with antibacterial coating and POAG
PANEL PC P21RL01
• 21.5 inch( 54.6 cm), Full HD
• 10-point capacitive multitouch
• Intel Core i3-1315U or Core i5-1335U
• Up to 64 GB DDR5 SO-DIMM
• 1 × 2.5-inch SATA SSD bay, 1 × M. 2 slot( 2280 / 2242) for NVMe or SATA SSD
• 2 × 2.5G LAN, Wi-Fi 5( 802.11ac)
• 2 × HDMI 2.0b, 8 × USB, 2 × COM; VGA optional
• 9 – 36 V DC input( optional, requires VOL01)
• Also available as M21AL01 in white with antibacterial coating and POAG
FROM £ 690 *
* Recommended trade prices in GBP, excluding VAT, available from authorised Shuttle distributors. Prices and specifications are subject to change without notice. E & OE.
