Hermetically Sealed Wire Thermocouple & RTD Sensors
EDITOR’ S CHOICE A SENSOR BUILT TO ENDURE
LABFACILITY
Hermetically Sealed Wire Thermocouple & RTD Sensors
An IP67 wire sensor that is hermetically sealed for use in corrosive or wet environments.
This versatile multi-purpose sensor has been specifically designed for use in and to protect against corrosion in harsh or wet environments. It has a quick response time and can be easily cleaned. The impermeable PFA insulated flexible wire thermocouple provides exceptional resistance to oils, fluids, gases, and chemicals and is electrically isolated.
The tip contains the sensing connection, which is weld-sealed to give a continuous PFA coating along the entire length and provide an atmosphere that is airtight and moisture-proof.
Available in IEC, ANSI and PRT calibrations, in 1,2 or 5m lengths, with bare tails or thermocouple plug termination.
• Hermetically sealed airtight tip
• Waterproof & suitable for insertion into liquids
• Oil & Chemical resistant PFA insulation
• For use in temperatures ranging from-75 to + 260 Degree C
• Electrically insulated tip tested to 1.0Kv as standard( can be tested at higher voltages)
• Flexible 7 / 0.2mm stranded conductors( 24AWG)
• 1.5 x 2.3mm nominal wire diameter( thermocouple)
• 2.6mm nominal wire diameter( RTD)
• Available with standard tails or mini thermocouple plug terminations
The impermeable PFA insulated flexible wire thermocouple provides exceptional resistance to oils, fluids, gases, and chemicals and is electrically isolated.
Typical Applications
• Pharmaceutical, Autoclaves and Sterilisation
• Food & Catering
• Environmental & Geothermal
• Laboratory and Research & Development
Website: www. labfacility. com Email: sales @ labfacility. com Tel: + 44( 0) 1243 871280 Tel: + 44( 0) 1909 569446
For further information, please visit www. labfacility. com
