KABELSCHLEPP Metool configures TOTALTRAX systems for XXL filling systems
CONTROL & AUTOMATION ALL-IN-ONE TIMES TWO
KABELSCHLEPP
KABELSCHLEPP Metool configures TOTALTRAX systems for XXL filling systems
As a specialist for automated filling and testing systems in automotive final assembly, SAT Anlagentechnik GmbH from Dägeling in Germany benefits from the current change towards electromobility. SAT Anlagentechnik involved KABELSCHLEPP Metool to ensure rapid implementation of an ambitious large order. The experts for cable carriers delivered 24 configured TOTALTRAX systems for a total of eight Movable Combi filling systems.
The customized systems from SAT Anlagentechnik fill vehicles with liquid and gaseous media during the production process, in compliance with the highest quality and process standards. The“ Combi” in the product name indicates that all media can be filled with a single system. It follows the assembly line(“ Movable”) and carries out filling step by step in several cycles.
The customized all-in-one systems not only place high requirements on the production at SAT Anlagentechnik, but also on all suppliers. Cable carriers had to be supplied as a turnkey complete system for a large project overseas – a challenge that KABELSCHLEPP Metool readily accepted. The TOTALTRAX specialists took on not only the design, harnessing, and testing of the cable carrier systems, but also provided the complete documentation and suitable transport packaging for shipping. Due to their size, the filling systems and TOTALTRAX systems were separated and shipped in several units after a function
Three cable carriers from the UNIFLEX Advanced 1995 series from KABELSCHLEPP Metool are used in each of the filling systems from SAT Anlagentechnik. The complete TOTALTRAX systems vary in the details and, in addition to the actual cable carriers, also comprise the harnessed cables and media hoses as well as the complete guide channels. Image: KABELSCHLEPP Metool
test in Germany. This meant that re-assembly of the individual components at the destination had to be easy and quick.
TOTALTRAX: large modular system without material dogma When configuring its customized TOTALTRAX systems, KABELSCHLEPP Metool always
The customized all-inone systems not only place high requirements on the production at SAT Anlagentechnik, but also on all suppliers.
considers all its cable carrier ranges and components. This provides an extensive modular system that can be used to quickly generate an optimum solution for any requirement.
Three cable carriers from the UNIFLEX Advanced 1995 series are used in each of the filling systems from SAT Anlagentechnik. They impress with their variability for this application. The complete TOTALTRAX systems vary in the details and, in addition to the actual cable carriers, also comprise the harnessed cables and media hoses as well as the complete guide channels.
“ There are a lot of parallels between our company philosophy and that of TSUBAKI KABELSCHLEPP,” explains Christian Chmiel-Hill, Head Of Supply Chain Management at SAT Anlagentechnik.“ Both companies are specialists for the design of customized solutions and can implement these with a great degree of flexibility. This prerequisite has resulted in a highly positive cooperation and successful implementation of the project.”
For further information, please visit www. tsubaki-kabelschlepp. com
50 PECM Issue 76
