differential movement and misalignments between pumps and the adjacent pipe work. While this is true to some extent, the main benefit of flexible pipe connectors is to interrupt the vibration pulses within the fluid created by the pump. When the pulses hit the arched construction of the connector, the regular frequency of these pulses is changed into random patterns. With random frequencies passing through the fluid, there is no opportunity for coinciding resonances between fluid and pipework.
For piping systems, we recommend opting for flexible pipe connectors and acoustic hangers. To suspend the piping, you will need to use durable hangers. The selection of which will depend on load, frequency and other system specifications.
Some applications require the flexible pipe connectors to be
We cannot stress enough the importance of getting vibration isolation right the first time around.
able to accept hot water, steam or chemicals passing through them at high pressure and elevated temperatures. Cheaper variations of flexible pipe connectors are generally moulded using EPDM with nylon reinforcement, and can become brittle if heated water passes through, leading to premature failure.
In contrast, Mason Industries’ flexible pipe connectors offer superb durability and can be tailored to suit each project. The Mason Safeflex range offers unparalleled protection against failure. Every connector is pressure tested in the factory to 150 per cent of rated pressure prior to release. The special design features include a uniquely robust flange design with Kevlar reinforcement, which has fantastic heat resistance, wrapped around a solid steel ring preventing pull out failures.
Pump isolation often requires an engineered solution. We cannot stress enough the importance of getting vibration isolation right the first time around. The first step to effective pump isolation is partnering with experienced acoustic engineers. These industry specialists will be able to specify quality vibration isolation products that can be tailored to your project and will last the test of time.
Are you looking for vibration isolation support for your pump application? Get in contact with Mason UK today to discuss your project’ s requirements.
For further information, please visit www. mason-uk. co. uk
