Stromag High Performance Brake ( HPB ) sets the future standard for dynamic performance for all types of application
Original equipment manufacturers ( OEMs ) in the crane and winch markets can now benefit from the highly modular Stromag electromagnetic spring applied HPB motor brake . This innovative solution sets new standards for dynamic performance , compactness , and flexibility in all applications . As safety requirements in the sector become ever more complex , the future orientated capabilities of the HPB place it at the forefront of motor brake innovation .
Offered in eight different sizes with three different friction linings , ingenious design allows each HPB variant to be offered in either two or four-face configurations without a large variance in brake size . As a result , a multitude of torque values can be generated from 80 Nm up to 6,400 Nm using the same basic architecture , making the brake highly suitable for use in marine , agricultural , construction , and machinery applications .
To exceed modern application standards and deliver a high safety margin , the development focus for the HPB centered on dynamic braking performance rather than simply end holding torque . Consequently , the HPB offers exceptional response times , heat dissipation , and time to stop across a wide speed range . Ideal for working , holding , and sudden stops , every HPB produced gets a run-in procedure followed by static torque test by Stromag in-house before delivery to provide quality
assurance and ensure optimal operation at different speeds .
The HPB allows a multitude of torque values to be generated using the same basic brake architecture , ideal for applications such as marine cranes .
Dynamic testing is also possible as an option .
Additionally , the increased braking performance of the HPB allows motors to be operated at a higher speed , improving operational efficiency . This can be a particular benefit for agricultural equipment working to demanding schedules during harvest , or ships loading and unloading cargo and equipment at port . In all cases , the HPB enables faster processes .
Flexibility of specification is another distinct advantage of the HPB . Every brake size can be fully customized to OEM requirement , but a standardized approach to spare parts means that a bespoke specification can be achieved with less components . This ensures a highly cost competitive , single source solution that actively reduces parts inventory , eases procurement , and streamlines maintenance .
One area of customization is the wide variety of connections , hubs , end caps , and flanges which can be modified to exactly fit an OEM ’ s motors . This enables accelerated assembly on the production line and straightforward retrofits into existing equipment designs . Other options include tachometer mounting , terminal boxes , anti-condensation heaters , and inductive proximity switches to monitor switching states or provide wear indication .
A brand of Regal Rexnord , Stromag has built an unrivalled reputation in heavy-duty braking solutions , and the robustness of the HPB illustrates why . An IP67 ingress protection rating , surface protection , and suitability for use across a wide temperature range ensures it is well equipped for outdoor operations , whether on-site , in the fields , or out at sea .
Ultimately , the HPB is a universal electromagnetic motor brake solution that can meet the needs of almost any crane or winch application . Inherent flexibility and ease of customization are combined with superior braking performance and high safety margin . Now , OEMs have access to a truly dynamic brake that can meet the future requirements of the most demanding applications .
For further information , please visit RegalRexnord . com
