Non-Magnetic Interconnect Products
In line with Cambion Electronics Limited product development strategy , the non-magnetic range has gone through extensive R & D . Contrary to popular belief , normal free machining grades of Brass are slightly magnetic , as they can contain traces of Iron and Nickel in their composition , rendering them unsuitable for sensitive applications , such as MRI ( Magnetic Resonance Imaging ) Scanners & Mine Detection Equipment . By careful control of raw material and plating selection and using the latest Magnetoscope technology magnetic permeability is tightly monitored ensuring the customer has absolute confidence . The range perfectly complements Cambion Electronics Limited existing product portfolio of industry favourites by retaining all the beneficial characteristics of the standard equivalents .
Sockets – A range of discrete sockets available in many mounting styles such as soldered , press fit , crimp , surface mount and stackable . Available to accept mating pin Dia . Ø0.41-2.06mm . The internal contact forms an hourglass shape with compound curvature that makes contact with 60 % of the circumference of the mated pin , ensuring no discontinuity particularly adept in high vibration applications .
Pins – Precision engineered to be compatible with loose piece sockets and thereby provide positive and lasting electrical connections with low contact resistance . Pin diameters are held to +/ - 0.05mm ( 0.002 ”).
Polygon Pin – A range of machined pins allowing for press-fit termination to PCBs . Available with various stand-off heights .
Terminal – A wide range of slotted , forked and pin styles in a range of sizes to suit standard board thicknesses . All variations are available insulated or non-insulated with a choice of mounting method . Cambion also offers a comprehensive range of insertion tools to assist assembly .
Shorting Links - Also known as Jumpers / Handbags . Male Insulated and Non-insulated . Insulator Polypropylene and available in standard colours Red / Blue and Black but others available upon request . In the following Pitch – 2.54mm ( 0.100 ”) to 12.7mm ( 0.500 ”).
Cambion is autonomous in its manufacturing capabilities with stamping , machining , moulding , automatic assembly and an equipped toolroom all under one roof at its ISO9001 , ISO14001 and AS / EN9100 certified Castleton , North Derbyshire facility . Cambion have a long and established pedigree for high performance electro-mechanical and inductive components serving the professional , automotive , military , aerospace , and industrial markets . Cambion is committed to ongoing product development , continual Investment , especially in the latest machinery , which has resulted in substantial manufacturing and assembly capabilities to cover a broad and comprehensive range of disciplines and technologies .
sales @ cambion . com or view www . cambion . com Call UK on + 44 ( 0 ) 1433 621555
