Highly robust single and multi-core high-voltage cables for construction and special vehicles
CONTROL & AUTOMATION THE HV 1000 C SERIES
SAB BRÖCKSKES
Highly robust single and multi-core high-voltage cables for construction and special vehicles
With the HV 1000 C series , SAB Bröckskes , one of the world ’ s leading manufacturers of special cables , has developed new highly robust single-core ( SC ) and multicore ( MC ) cables for high-voltage wiring in construction , agricultural , and special vehicles . The HV single-core , available in eight standard dimensions with nominal cross-sections from 6 mm2 to 95 mm2 , meets the special requirements for safety and reliability in electrically or hybrid-driven utility vehicles . The multi-core version is available in dimensions from 2 x 2.50 mm ² to 5 x 6.00 mm ². Due to its high mechanical strength and resistance to environmental influences as well as its very good oil and temperature resistance , the HV single core solution designed for nominal voltages of up to 1,000 V AC / DC is suitable , for example , for the electrical connection of inverters and electric motors .
The HV multi-core cable is used , for example , as a connecting cable to the cabin heater , the e-compressor or the HV heat pump in electric and hybrid vehicles . The double EMC-shielded high-voltage cables with bare copper stranding and orange-colored TPE-U sheathing have a low-temperature resistance down to -50 ° C according to DIN EN 60811-506 and withstand temperatures of up to + 125 ° C for a operating time of up to 2,000 hours . The extremely tensile , abrasion and shear resistant outer sheath allows tight bending radii and , in many cases , eliminates the need for installation with additional protective tubing . Other quality and safety features include flame-retardant and self-extinguishing material properties in accordance with IEC 60332-1-2 as well as standardized high resistance to mud , UV , ozone , and salt water . All materials are free of harmful substances and meet RoHS criteria . In addition to the standard designs , SAB Bröckskes also offers intermediate cross-sections of e . g . 8 mm2 as well as sheaths in other color variants on request .
The extremely tensile , abrasion and shear resistant outer sheath allows tight bending radii and , in many cases , eliminates the need for installation with additional protective tubing .
Robust , process-safe high-voltage cable for connecting electric motors in mobile machinery , agricultural and special vehicles .
For further information , please visit www . sab-cable . com
