F Series Swivels for Use on Hose Reels
A rotary union , or ‘ Swivel Joint ’ is used to transfer fluid across a rotating interface . At Rotaflow we have produced Swivel Joints for many applications within all areas of engineering and for all over the world : From Brewery , Food and Drink , Process , Drilling & Mining , Oil & Gas to Nuclear , Chemical and Subsea .
We provide solutions that have enabled all manner of different fluids ( including oils , fuels , corrosives , food ) and / or air / steam to be transferred through awkward , and often , already established production infrastructure . With almost 40 years of experience , we have designed and manufactured swivels to withstand and perform effectively when faced with many tricky environmental factors : Overcoming issues with heat , pressure , size and material choice . Our dual roller and ball bearing race designs mean you get a longer life ; an increased reliable service , and a higher capacity for axial and radial loading and all without leakage . So , less downtime and more productivity .
Swivel joints will allow the movement on a slowly rotating drum or remove the damaging effect of twisting on hoses . We manufacture in Carbon Steel and 316 SS with “ specials ” in any grade of metal to suit customer specification . With bores ranging from 0.25 ” to 40 ”; Vacuum duty to 20,000PSI and multi passaged designs allowing multiple flows of fluid though a single unit .
Photo attached shows F Series Swivels having their first coat of paint in readiness for despatching to America .
To find out more please visit our website and / or give us a call . Tel : + 44 ( 0 ) 1663 735003 sales @ rotaflow . com www . rotaflow . com
Articulated Pipework
Torsion In Hoses
Rotating Cylinders
Bingswood Trading Estate Whaley Bridge | High Peak | SK23 7LY | UK

Fluid

Carrying

Flexibility

Swivel Joints

Swivel joints allow pipework to
pressure 1 / 4 ” to 40 ” and beyond . Vacuum to over 20,000psi . Stock and bespoke production .
Unique bearing / seal design for longer life .
ISO 9001 CE marked where applicable .
Tel : + 44 ( 0 ) 1663 735003 E-mail :

Bulk liquid dispensing skids for mobile and static applications

Self-contained mobile demountable skids for IBC delivery vehicles
Land based skids for loading and unloading of road tankers with fuels , oils and chemicals
IBC and barrel filling
PD or centrifugal pumps for handling all types of petro-chemical liquids
Highly accurate LC flow meters with mechanical or electronic registers
Dispensing systems designed to suit customers specific requirements in terms of liquids and flow rates
Electric , hydraulic or donkey engine drive options
Optional transfer methods , hose reels , loading arms custom hoses and couplings
Galvanized or stainless-steel framework for protection against the elements
Liquid handling solutions for the petro-chemical industry
Alpeco Limited | 66-69 Rabans Close | Aylesbury | Bucks HP19 8RS t 01296 619510 | alpecoltd . com
