MEASUREMENT & MONITORING
Line optics : An excellent option for infrared temperature measurements
Expanded functionality of Impac pyrometers especially for wire production and pouring stream measurements
IMPAC pyrometers Series 6 Advanced represent the “ flagship-class ” of small-sized infrared thermometers by Advanced Energy . They are extremely fast and highly accurate digital pyrometers ( single color or 2-color ) with very long temperature ranges , analog output , digital interface , and focusable optics .
Pouring stream measurements with Line optics and horizontally enlarged spot .
Different models are available with integrated LED display with laser targeting light , view finder , or integrated color-TV camera .
Besides the standard optical heads , the pyrometers ISR 6 and IGAR 6 are also available with integrated line optics as an option .
These special “ line optics ” offer significantly wider measurement spots in shape of a line and provide additional advantages for steel applications , especially for wire production or pouring stream measurements .
The line shaped spot guarantees that vibrating or oscillating wires or a moving pouring stream do not move out of the pyrometer ’ s target spot . Thereby the wires respectively the pouring stream need to be aligned diagonally to the line shaped spot .
In combination with the fast response time of 2 ms even very fast processes can be measured reliably . The optics can be manually adjusted at all distances between 210 mm and 5000 mm .
Pyrometer Series 6 Advanced w . different optics
www . advancedenergy . com | info @ aei . com
