SWITCHES & SENSORS
THE SENZTX
PROCESS SENSING TECHNOLOGIES
Compact O2 transmitter for reliable measurement of oxygen concentration
Engineers are constantly looking for new and innovative ways to improve the efficiency of their processes . In many cases , this involves finding a product that can be easily integrated and provides flexibility . When it comes to oxygen transmitters , the SenzTx from Process Sensing Technologies ( PST ) is designed to meet the challenges of demanding industrial applications . Simple to install and easy to maintain , the SenzTx Oxygen Transmitter is suitable for direct insertion or remote installations and can be used in numerous applications including oxygen and nitrogen gas generation , glove box purge and leak detection , industrial gas purity applications , and measurement solutions for medical gases . The SenzTx utilizes proven sensor technology to provide accurate oxygen concentration measurement . With a choice of zirconia or electrochemical sensor technology , the SenzTx offers reliability , accuracy , and flexibility with a broad measurement capability with transmitters covering the ranges of measurement from 0 ... 10ppm up to 100 % oxygen .
SenzTx Electrochemical Flow Through Sensor
Zirconia sensor technology The zirconia oxygen sensor is a non-depleting zirconia solid electrolyte sensor . It offers fast response time from ambient oxygen levels with virtually no drift , has long calibration intervals , and an expected operational life of three to five years with very little user intervention . While not able to perform measurements in a hard vacuum or a pressurized gas environment , the construction of the zirconia sensor will not be damaged if exposed to these conditions . The zirconia sensor also has low cross-sensitivity to other gases and is not position or orientation sensitive . This rugged measurement technology enables a wide range of measurement applications in many industries .
Electrochemical sensor technology The electrochemical sensor performs measurements at ambient temperatures enabling oxygen measurements in combustible gases such as Hydrogen or a process gas containing hydrocarbons .
The low power requirement of the electrochemical sensor enables low power and loop-powered instrumentation to be used making for easier integration in to control systems . In the absence of oxygen there is no output from the electrochemical sensor , meaning only one calibration is required . Ease of integration and low maintenance The choice of KF-40 flange or flow through block for the process connection enables easy mechanical integration either at the point
SenzTx Zirconia Sensor with KF40 Flange Configuration
of measurement . The flow through block can also be specified with an orifice in the inlet port to ensure the correct pressure and flow over the sensor . The SenzTx is a self-contained calibrated transmitter . The transmitter offers a choice of analog and digital outputs through a single electrical connector and no additional signal processing is required to achieve an accurate measurement . The compact size of the transmitter further enhances the ease of integration and installation .
For more information , visit www . ProcessSensing . com / SenzTx
