Fischer Freedom ™ is rugged
– tested and proven
The multiple award-winning Fischer LP360™ 7-pin connector in metal
is innovative AND reliable: it has undergone stringent and thorough
testing and qualification.
Fischer Connectors’ solutions are recognized worldwide for their
ruggedness and durability. For the first time, discover some of the
mechanical and environmental tests that products undergo to prove
their compliance with the highest reliability and quality standards
through 8 short videos. These videos describe the testing processes
conducted in our laboratory, as well as two demonstrations carried out
“in the field”.
The videos include six standard tests conducted on the Fischer
LP360™ 7-pin connector (the first product in the Fischer Freedom™
Series) in the testing laboratory of Fischer Connectors’ headquarters
in Saint-Prex, Switzerland. In two field applications, we also show
how the connector behaves in water and how easily its plug and
receptacle can be cleaned.
You can view the videos at www.fischerconnectors.com/uk/en/fischer-
freedomtm-series-tests-proofs:
1. Endurance test
• 10,000 mating operations / 5,000 full rotations
2. Bending (flexing) test
• 5,000 oscillations
3. Random vibration test
• 9.26 Grms overall acceleration
4. Immersion test
• IP68 sealed – 2 bars (equivalent to 20m) for 24 hours
5. IP68 degree of protection – field application
• Perfectly functional under water – immersion in a fish tank
6. Field cleaning – field application
• Fully cleanable plug & receptacle
7. Corrosion resistance test
• Salt fog 1,000 hours / 5% salt solution, 35 °C
8. High & low temperature test
• -55 °C to +135 °C (connectors only)
The Fischer LP360™ has also undergone stringent and thorough
testing according to international industry and military standards
such as IEC, EIA, MIL-STD-202 and MIL-STD-810.
More information on relevant tests can be found at
www.fischerconnectors.com/sites/default/files/specifications/fischer_
freedom_series_techspecs_v2.6_02.20.pdf.
AWARD-WINNING
BREAKTHROUGH PLUG & USE
CONNECTIVITY
■
■
■
No key code for 360° mating &
optimized cable management
Fully cleanable, IP68
Easy to integrate into
devices OR garments
