MEASUREMENT & MONITORING
Innovative Oil in Water Analysis
from Turner Designs Hydrocarbon
Instruments
Turner Designs Hydrocarbon Instruments
introduces the new standard in grab sample oil
in water analysis. The TD-550’s optics are suitable
for crude and other heavy oils. The TD-560 adds
a second optical channel for detecting lighter
hydrocarbons, such as BTEX, gas condensates,
fuels, and lube oils.
Applications: Industrial discharge, waste water,
cooling water, intake protection, produced
water, and treatment verification.
Features
• Low cost per sample analysis
• Large full-color touch screen interface
• Advanced data logging and graphing
capabilities
• Results can be correlated to official lab
methods such as USEPA 1664A and ISO 9377-1
For more information on the TD-550 and
TD-560 Oil in Water Analyzers as well
as the complete TDHI product line, visit
oilinwatermonitors.com.
Newmax Precision Ltd
NEWMAX PRECISION Ltd, component
manufacturers based near Heathrow on M25,
are always striving to stay technically ahead
by acquiring the latest in 5-Axis machining
technology.
With our Matsuura MX-330, 90 tool multi pallet
Machining Centre, backed up with the latest
Hypermill 5-Axis programming software, we can
meet all the latest technical demands needed for
the modern Sub-Contracting Industry.
Detecting Leaks from Electrical
Circuit Breakers
FLIR Systems has published a new application
spotlight that addresses the challenge that
electrical power stations face in detecting gas
leaks from their Sulfur hexafluoride (SF6)
circuit breakers. Sulfur hexafluoride circuit
breakers protect electrical power stations and
distribution systems by interrupting electric
currents, when tripped by a protective
relay. Advantages of sulfur hexafluoride circuit
breakers over other media include lower
operating noise, no emission of hot gases, and
relatively low maintenance.
For a copy of this application spotlight
please visit www.flir.eu/instruments/
utilities/application-spotlight-inspect-sulfur-
hexafluoride-sf6-circuit-breakers/. For more
information about using optical gas imaging
cameras for leak detection in electrical
power substations / transmission please visit
www.FLIR.com/substation-transmission or
contact FLIR Systems on +32-3665-5100 /
[email protected].
Submersible Load Cells
Lower the Cost of Large
Tidal Turbine Designs
The EPICTidal Team (Lab-Sea-Systems, Cranfield
University and Designcraft Ltd) wanted to know
the performance implications of employing
lower cost manufacturing methods of large scale
tidal turbine rotors.
SOLUTION – Applied Measurements DDEN
Submersible Load Cells
Utilising the 10 Pallet system, gives us the ability
to run unmanned, ensuring us the flexibility
to work with and meet all client deadlines.
We are an ISO 9001:2015 registered company,
committed to high standards of quality, delivery
and competitive pricing. Go to our web site
www.newmax.co.uk and upload a drawing for
us to quote. The rotor blade design was coupled to a
submersible tidal turbine test rig containing 2
DDEN submersible load cells. Once placed in
a state-of-the-art test tank, the team were able
to increase the size, flow rate and turbulence
levels within the tank. The first DDEN load cell
measured the torque and the second measured
the thrust of the tidal rotor design.
Newmax Precision Ltd
T: 01753 631112
www.newmax.co.uk If you have a torque application you would
like to discuss, please contact Applied
Measurements on (+44) 0118 981 7339 or visit
appmeas.co.uk/discuss-torque/
146
PECM Issue 38
The new ACEINNA MCX1101
current sensor is the industry’s
first high accuracy current sensor
based on AMR Technology
Highly accurate, wide bandwidth, fully isolated
and affordable current sensing, this “All in One”,
easy to integrate Current Sensor provides power
management for power inverters and motor
control, industrial robots and manufacturing
systems, telecom and server farm power
supplies, automotive EV charging stations, IoT
appliances, home automation and many other
tech applications
The new ACEINNA integrated, Current Sensors
provide the best performance for the price in
the industry. There are other AMR based current
sensing solutions on the market, but they require
a great deal of integration to make them work.
Ours are plug and play.
www.aceinna.com/current-sensors
PhoenixTM Ltd - Phoenix
Temperature Measurement
PhoenixTM Ltd design and manufactures ‘thru-
process’ temperature monitoring systems for
the heat treatment industry. Providing solutions
for various industrial sectors including heat
treatment of aluminium and steel, ranging
from raw materials (Slab, billets etc) to finished
products, such as carburizing automotive
components. Other applications include Paint
and Powder Coating, Food Processing (HACCP),
Glass Processing and Ceramic Firing. Protected
by a thermal barrier, the data logger travels
through the process and thermocouples
measure the product temperature. A historic
temperature record (Profile graph or TUS)
is collected which then can be analysed
using Industry specific software to generate
AMS2750E and CQI-9 compliant reports.
Understand, Control, Optimize and Certify your
furnace process to guarantee product quality,
process operation efficiency and regulatory
compliance.
Tel:+44(1353)223100 | [email protected]
www.phoenixtm.com
