66
WOOD SHELVES / TOPS & CORBELS
|
L : Laminate M : Metal P : Paint R : RTF Vinyl Wrap S : Stain NA : Not Available
CATEGORY
|
White , Granite , Cloud , Storm , Onyx |
Satin White |
Wengi |
Satomi , Tsuki1 , Tsuki2 , Canyon , Sandstone , Weathered Gray |
Wood Stain |
Paint |
WOOD SHELVES THERMOFOIL WOOD
Finished 1-Sided Shelf |
|
|
|
DIMENSION |
MODEL NUMBER |
12 " x 96 " |
AWSC1296 |
|
12 " |
1 1 / 4 " |
L L L L L L |
|
3 / 4 " |
|
|
Finished 2-Sided Shelf |
|
|
|
DIMENSION |
MODEL NUMBER |
12 " x 96 " |
AWSC1296B |
|
|
|
|
12 " |
1 1 / 4 " |
L L L L L L |
Tops
DIMENSION |
MODEL NUMBER |
24 1 / 2 " x 48 " |
AWT4 |
24 1 / 2 " x 96 " AWT8
3 / 4 "
• Finished on 3 edges
• Supports 48 " openings
• RTF is 1 " thick with built-in edge
• Wood and Paint are 1 " thick with veneer surfaces
R R R R S P
CORBELS
• Used to support countertop overhangs
• Clear specification requirements with contertop supplier
• Recommended space of 32 " to 48 "
Standard |
7 ", 10 ", 13 " |
|
ACB7 - Use with overhang up to 11 " ACB10 - Use with overhang up to 14 "
ACB13 - Use with overhang up to 17 "
|
6 "
9 "
|
P |
P * |
S ** |
NA |
S |
P |
* Satin White uses White ( 30 ) ** Wengi uses Java Stain ( 25 )
12 "
SPECIALTY PARTS & ACCESSORIES
Metal ACBM9 - Use with overhang up to 12 "
Countertop Build-Up Strips APBU - Use with overhang up to 12 "
9 "
5 / 8 "
• Use strips for Formica build-up
2 5 / 8 "
• Edgebanded one side , must specify finish
• Rip into three equal parts to cover front , back and sides with one piece per 8 ’ LF of base
9 "
M M M M M M
DIMENSION
MODEL NUMBER 5 / 8 " x 2 5 / 8 " x 96 " APBU58
