Replacement Drawer Parts
Replacement Drawers- Fully Assembled with Glides and Runners( PAD)
• NOTE: Drawer Front is not Included
• Specify drawer grade when ordering
STD = Standard DT = Dovetail Upgrade
DRAWER WIDTH
KNEE CABINETS
Standard Metabox Drawer
Upgrade Drawer Dovetail
21 " DEEP DRAWERS 24 " DEEP DRAWERS
6 " Drawer Front( i. e. Upper Vanity Drawers)
6 " PADU0621
Large Drawer Front( i. e. Lower Vanity Drawers)
* Excluding large drawer fronts that utilize Desk File drawers or Large Pot & Pan drawers ** Also used for B2CT, BRAP and OVC large drawers
6 " Drawer Front( i. e. Upper Base Drawers)
9 " PADU0921 PADU0924
Large Drawer Front *( i. e. Lower Base Drawers)
12 " PADU1221 PADL1221 PADU1224 PADL1224
Large Desk Drawer( i. e. File and Lower Drawer)
Large Pot & Pan Drawer Front **
15 " PADU1521 PADL1521 PADU1524 PADL1524 PADF1524 PADPP1524 16 " PADU1624 18 " PADU1821 PADL1821 PADU1824 PADL1824 PADF1824 PADPP1824 19 " PADU1924 21 " PADU2121 PADL2121 PADU2124 PADL2124 PADPP2124 24 " PADK2421 PADU2421 PADL2421 PADU2424 PADL2424 PADF2424 PADPP2424 27 " PADU2721 PADU2724 30 " PADK3021 PADU3021 PADU3024 PADF3024 PADPP3024 33 " PADU3321 PADU3324 PADPP3324 36 " PADK3621 PADU3621 PADU3624 PADF3624 PADPP3624 39 " PADK4221 PADU3921 PADU3924 42 " PADU4221 PADU4224
REPLACEMENT PARTS
Metabox Rollout Fronts
DRAWER HEIGHT
12 " WIDTH
15 " WIDTH
18 " WIDTH
21 " WIDTH
24 " WIDTH
27 " WIDTH
30 " WIDTH
33 " WIDTH
36 " WIDTH
39 " WIDTH
42 " WIDTH
4 " DR1204 DR1504 DR1804 DR2104 DR2404 DR2704 DR3004 DR3304 DR3604 DR3904 DR4204
Replacement Drawer Fronts / Headers( DW)
• Pilot holes drilled for standard hardware connectors
• Grain on Lenox Drawer Front runs Vertical
• Grain on Mission and Kadan Drawer Front runs Horizontal
DRAWER WIDTH 3 " TALL 6 " TALL 10 " TALL 12 " TALL 15 " TALL
6 " DW0606 * 9 " DW0906 12 " DW1206 DW1210 DW1212 15 " DW1506 DW1510 DW1512 DW1515 16.5 " DW1606 18 " DW1806 DW1810 DW1812 DW1815 19.5 " DW1906 21 " DW2106 DW2110 DW2112 DW2115 24 " DW2403 DW2406 DW2410 DW2412 DW2415 27 " DW2706 30 " DW3003 DW3006 DW3012 33 " DW3306 DW3312
APRON SINK FRONT
36 " DW3603 DW3606 DW3612 OA3612 39 " DW3906 42 " DW4203 DW4206 48 " DW4806
* Features slab drawer front for all door styles excluding Kadan which features the standard Kadan drawer profile.
83
