PALBIT - katalog | KL-TECH s.r.o. | www.klte.cz Palbit_katalog | Page 639

Threading Toolholders | Suportes de Roscagem | Soportes de Roscado
Threading Tool | Ferramenta | Herramienta
Dimensions
Anvil Anvil Screw Insert Screw Torx Key
Order
Code Reference Insert Type 212244300 SXANL 0808 H11 EL11 - P0260700 XT08
212244400 SXANL 1010 H11 EL11 - P0260700 XT08
212123200 SXANL 1212 H16 EL16 P5000790 P5401390 XT10
212123400 SXANL 1616 H16 EL16 P5000790 P5401390 XT10
212123500 SXANL 2020 K16 EL16 P5000790 P5401390 XT10
212123800 SXANL 2525 M16 EL16 P5000790 P5401390 XT10
212124400 SXANL 3232 P16 EL16 P5000790 P5401390 XT10
212123900 SXANL 2525 M22 EL22 P8000990 P8001590 XT20
212124200 SXANL 3232 P22 EL22 P8000990 P8001590 XT20
212244500 SXANL 2525 M27 EL27 P0500990 P0502200 XT25
212244600 SXANL 3232 P27 EL27 P0500990 P0502200 XT25
Order
Code Reference Insert Type 212244700 SXANR 0808 H11 ER11 - P0260700 XT08
212244800 SXANR 1010 H11 ER11 - P0260700 XT08
212123100 SXANR 1212 H16 ER16 P5000790 P5401390 XT10
212053800 SXANR 1616 H16 ER16 P5000790 P5401390 XT10
212053100 SXANR 2020 K16 ER16 P5000790 P5401390 XT10
212053200 SXANR 2525 M16 ER16 P5000790 P5401390 XT10
212124300 SXANR 3232 P16 ER16 P5000790 P5401390 XT10
212053000 SXANR 2525 M22 ER22 P8000990 P8001590 XT20
212124100 SXANR 3232 P22 ER22 P8000990 P8001590 XT20
212244900 SXANR 2525 M27 ER27 P0500990 P0502200 XT25
212245000 SXANR 3232 P27 ER27 P0500990 P0502200 XT25
Stock
Dimensions
Anvil Anvil Screw Insert Screw Torx Key
Stock
R
E
E - 42
PAG E - 39
PAG E - 47
