two phases . While the least predictable floods ( Fig . 1 , red dots ) are found among the synoptic patterns corresponding to those known as Atlantic Ridge and Blocking ( southern synoptic patterns , as opposed to the zonal patterns corresponding to the NAO ). However , the floods with the greatest impact ( Fig . 1 , yellow dots ) are located in less extreme patterns but closer to NAO +/ NAO- . These results can be seen in figure 2 , which shows the spatial distribution of the mean SLP of the highest impact values ( Fig . 2a ), which seems to be governed by NAO +, as in the more predictable events ( Fig . 2b ). However , the less predictable events ( Fig . 2c ) seem to correspond more to a mixture of synoptic patterns including blocking .
Discussion and conclusions Therefore , this study concludes that : 1 ) The seasons with the highest number of floods are winter and spring and the least summer ;
2 ) The Duero basin is where these events tend to last the longest , the Northern and Ebro basins are those that have suffered the greatest number of floods and that the hydrographic basin whose floods cause the greatest number of deaths is the Northern basin ;
3 ) The synoptic patterns associated with extremes of precipitation that lead to flooding are the North Atlantic oscillation , especially in its positive phase , which is also the most predictable type of pattern , which could help us to create an early warning system to avoid impacts associated with flooding in Spain . Finally , it is difficult to obtain data on floods , as there is no free access to them and sometimes there is a lack of data observed in certain places .
Why is this work important and what does it contribute to improving the Andalusian environment ?
The results of this final degree project , as well as being innovative , are important because , on the one hand , they extend the historical information on floods in Spain ( including Andalusia ) with the generation of a new database where they are catalogued according to their impact , associated synoptic pattern , predictability and by hydrographic basin , which is fundamental as a starting point for future research . On the other hand , the result related to predictability , in addition to being done for the first
Para poder detectar la predictibilidad de eventos extremos , relacionamos las condiciones atmosféricas de dicho momento con los patrones sinópticos que rigen el clima en la península ibérica . Estos son : Las oscilaciones del Atlántico Norte ( NAO ) en fase positiva y negativa ( NAO +/ NAO- ), Atlantic Ridge ( AR ) y Blocking .
Como resultado se obtuvo que las inundaciones más predecibles ( Fig . 1 , puntos verdes ) son las que tienen patrones sinópticos asociados a la Oscilación del Atlántico Norte ( NAO ) en sus dos fases . Mientras que las menos predecibles ( Fig . 1 , puntos rojos ) se encuentran entre los patrones sinópticos correspondientes a los conocidos como Atlantic Ridge y Blocking ( Patrones sinópticos meridionales , opuestos a los patrones zonales correspondientes a la NAO ). Sin embargo las inundaciones con mayor impacto ( Fig . 1 , puntos amarillos ) se situan en patrones menos extremos pero más cercanos a NAO +/ NAO- . Estos resultados son apreciables en la figura 2 donde se muestra la distribución espacial de la SLP media de los valores de mayor impacto ( Fig . 2a ), la cual parece estar regida por una NAO +, al igual que en los eventos más predecibles ( Fig . 2b ). Sin embargo , los eventos menos predecibles ( Fig . 2c ) parecen corresponder más a una mezcla de patrones sinópticos entre los que se encuentra el blocking .
Discusión y conclusiones Por tanto , con este estudio se concluye que : 1 ) Las estaciones con mayor número de inundaciones son invierno y primavera y la que menos verano ;
2 ) La cuenca del Duero es donde mayor duración suelen tener estos eventos , la del Norte y la del Ebro son las que mayor número de inundaciones han sufrido y que la cuenca hidrográfica cuyas inundaciones dejan mayor número de fallecidos es la cuenca Norte ;
3 ) Los patrones sinópticos asociados a extremos de precipitación que conllevan inundaciones son la oscilación del Atlántico Norte , sobre todo en su fase positiva , siendo además el tipo de patrón más predecible , lo cual nos podría ayudar a crear un sistema de alerta temprana para poder evitar impactos asociados a inundaciones en España . Por último remarcar la dificultad para la obtención de datos sobre inundaciones ya que no hay acceso gratuito
