HSS end mills

WTM

T-slot
DIN 851
INFO
TYPHOON TA-HTA-4HTA
TYPHOON PU-HPU
TYPHOON SUH
P
M
K
N
S
H
�
�
�
�
� 1st choice
� suitable
TYPHOON ALH
TYPHOON HRC
T SLOT
TYPHOON SUH MINI
D( d11)
D( d11) Tol.
d( h6)
d1( h12)
d1 Tol.
H( d11)
H Tol.
L
z
EDP No.
Stock
12.5
-0.050/-0.160
10
5
0 /-0.012
6
-0-030/-0.105
57
6
WTM125
h
16
-0.050/-0.160
10
6.5
0 /-0.015
8
-0-040/-0.130
62
6
WTM160
h
18
-0.050/-0.160
12
8
0 /-0.015
8
-0-040/-0.130
70
6
WTM180
h
19
-0.065/-0.195
12
8
0 /-0.015
9
-0-040/-0.130
71
6
WTM190
h
21
-0.065/-0.195
12
10
0 /-0.015
9
-0-040/-0.130
74
6
WTM210
h
22
-0.065/-0.195
12
10
0 /-0.015
10
-0-040/-0.130
75
6
WTM220
h
25
-0.065/-0.195
16
12
0 /-0.018
11
-0-050/-0.160
82
6
WTM250
h
28
-0.065/-0.195
16
13
0 /-0.018
12
-0-050/-0.160
83
6
WTM280
h
32
-0.080/-0.240
16
15
0 /-0.018
14
-0-050/-0.160
90
8
WTM320
h
36
-0.080/-0.240
25
17
0 /-0.018
16
-0-050/-0.160
103
8
WTM360
h
