KL-TECH s.r.o | www.klte.cz HSS end mills CUTTING PARAMETERS INFO WDC 45° - 60° N TYPHOO HTA TA-HTA-4 Material Group ISO 513 N TYPHOO PU-HPU N TYPHOO SUH N TYPHOO ALH N TYPHOO HRC N TYPHOO I SUH MIN N TYPHOO HL C-SD-TA LFTA SUTA /CO HSS-HSS DRILLS G2 MDTA P HF VH/U MEF ALU MEX UH -HSSP HSS/CO LS END MIL CARBIDE BURRS 692 DOVETAIL B 45°-60° P1 P2 P3 P4 M1 M2 K1 Hardness/Rm < 800 N/mm² < 750 N/mm² < 350 HB ap x ae 0.2D x 0.15D 0.2D x 0.15D 0.2D x 0.15D Vc (m/min) 30-50 15-25 30-40 D (mm) z n (rpm) 16 20 22 25 28 32 38 6 6 6 8 8 10 12 800 640 580 510 450 400 340 fn Vf (mm/rev) (mm/min) 0.015 0.017 0.018 0.020 0.023 0.025 0.028 70 65 65 80 80 100 115 n (rpm) 400 320 290 250 230 200 170 fn Vf (mm/rev) (mm/min) 0.011 0.012 0.013 0.014 0.016 0.018 0.020 25 20 20 20 20 20 20 n (rpm) 700 560 510 450 400 350 290 N1 K2 N2 N3 N4 0.2D x 0.15D 50-70 fn Vf (mm/rev) (mm/min) 0.013 0.014 0.015 0.017 0.019 0.021 0.024 55 45 45 45 45 45 40 n (rpm) 1190 960 870 760 680 600 500 fn Vf (mm/rev) (mm/min) 0.017 0.018 0.020 0.022 0.025 0.028 0.031 120 105 105 100 100 100 90
