UH - < 70HRC - Corner radius
UH413
OSAWA
NORM
<70
INFO
cylindrical shank, 4F, reduced neck, corner radius, long
TYPHOO
N
TA-HTA-4
HTA
CR
TYPHOO
N
PU-HPU
TYPHOO
N
SUH
P
M
,
K
N
S
,
+ 1st choice
H
CR
+
, suitable
TYPHOO
N
ALH
TYPHOO
N
HRC
SIDE MILLING
TYPHOO
N
SUH MIN
I
D D Tol. CR CR Tol. d(h6) l l1 d1 L z EDP No. Stock
6 0/-0.025 0.30 +/-0.010 6 10 60 5.50 125 4 UH4130600360 h
6 0/-0.025 0.50 +/-0.010 6 10 60 5.50 125 4 UH4130600560 h
6 0/-0.025 1.00 +/-0.010 6 10 60 5.50 125 4 UH4130601060 h
8 0/-0.030 0.30 +/-0.010 8 12 60 7.40 125 4 UH4130800360 h
8 0/-0.030 0.50 +/-0.010 8 12 60 7.40 125 4 UH4130800560 h
8 0/-0.030 1.00 +/-0.010 8 12 60 7.40 125 4 UH4130801060 h
8 0/-0.030 2.00 +/-0.010 8 12 60 7.40 125 4 UH4130802060 h
h
10 0/-0.030 0.30 +/-0.010 10 14 85 9.20 125 4 UH4131000385 10 0/-0.030 0.50 +/-0.010 10 14 85 9.20 125 4 UH4131000585 h
10 0/-0.030 1.00 +/-0.010 10 14 85 9.20 125 4 UH4131001085 h
h
10 0/-0.030 2.00 +/-0.010 10 14 85 9.20 125 4 UH4131002085 12 0/-0.030 0.50 +/-0.010 12 16 110 11.00 150 4 UH41312005110 h
12 0/-0.030 1.00 +/-0.010 12 16 110 11.00 150 4 UH41312010110 h
12 0/-0.030 2.00 +/-0.010 12 16 110 11.00 150 4 UH41312020110 h
16 0/-0.030 0.50 +/-0.010 16 22 110 15.00 150 4 UH41316005110 h
16 0/-0.030 1.00 +/-0.010 16 22 110 15.00 150 4 UH41316010110 h
