UH - < 70HRC - Corner radius
UH211
<70
OSAWA
NORM
INFO
cylindrical shank, 2F, extended and reduced neck,
corner radius
CR
CR
TYPHOO
N
TA-HTA-4
HTA
TYPHOO
N
PU-HPU
TYPHOO
N
SUH
M
,
+ 1st choice
K
N
S
,
, suitable
TYPHOO
N
ALH
H
P
+
TYPHOO
N
HRC
α
SQUARE RIB
TYPHOO
N
SUH MIN
I
actual length according to _ angle
D D Tol. CR CR Tol. d(h6) l l1 d1 L z 30’ 1° 1°30’ 2° 3° EDP No. Stock
1 0/-0.012 0.10 +/-0.010 4 2 4 0.95 50 2 4.36 4.60 4.86 5.16 5.89 UH2110100104 h
1 0/-0.012 0.10 +/-0.010 4 2 6 0.95 50 2 6.46 6.82 7.21 7.66 8.74 UH2110100106 h
1 0/-0.012 0.10 +/-0.010 4 2 8 0.90 50 2 8.45 8.73 9.00 9.27 9.81 UH2110100108 h
1 0/-0.012 0.20 +/-0.010 4 2 4 0.95 50 2 4.36 4.60 4.86 5.16 5.89 UH2110100204 h
1 0/-0.012 0.20 +/-0.010 4 2 8 0.95 50 2 8.57 9.04 9.56 10.15 11.18 UH2110100208 h
1 0/-0.012 0.30 +/-0.010 4 2 4 0.90 50 2 4.31 4.44 4.57 4.70 4.97 UH2110100304 h
1 0/-0.012 0.30 +/-0.010 4 2 8 0.95 50 2 8.57 9.04 9.56 10.15 11.18 UH2110100308 h
1.5 0/-0.012 0.10 +/-0.010 4 2.5 6 1.45 50 2 6.30 6.52 6.75 7.01 7.57 UH2110150106 h
1.5 0/-0.012 0.10 +/-0.010 4 2.5 10 1.45 50 2 10.43 10.8 11.19 11.61 12.55 UH2110150110 h
1.5 0/-0.012 0.20 +/-0.010 4 2.5 8 1.45 50 2 8.37 8.66 8.97 10.06 UH2110150208 h
9.31
1.5 0/-0.012 0.20 +/-0.010 4 2.5 12 1.45 50 2 12.50 12.94 13.40 13.91 15.03 UH2110150212 h
2 0/-0.012 0.10 +/-0.010 4 3 6 1.95 50 2 6.30 7.57 UH2110200106 h
2 0/-0.012 0.10 +/-0.010 4 3 12 1.95 50 2 12.50 12.94 13.40 13.91 15.03 UH2110200112 h
2 0/-0.012 0.20 +/-0.010 4 3 6 1.95 50 2 6.30 7.57 UH2110200206 h
2 0/-0.012 0.20 +/-0.010 4 3 12 1.95 50 2 12.50 12.94 13.40 13.91 15.03 UH2110200212 h
2 0/-0.012 0.30 +/-0.010 4 3 8 1.95 50 2 8.37 10.06 UH2110200308 h
2 0/-0.012 0.30 +/-0.010 4 3 12 1.95 50 2 12.50 12.94 13.40 13.91 15.03 UH2110200312 h
2 0/-0.012 0.30 +/-0.010 4 3 16 1.95 50 2 16.64 17.21 17.84 18.50 - UH2110200316 h
2 0/-0.012 0.50 +/-0.010 4 3 6 1.95 50 2 6.30 7.57 UH2110200506 h
2 0/-0.012 0.50 +/-0.010 4 3 12 1.95 50 2 12.50 12.94 13.40 13.91 15.03 UH2110200512 h
3 0/-0.012 0.30 +/-0.010 6 4.5 10 2.80 55 2 10.71 11.04 11.38 11.72 12.40 UH2110300310 h
3 0/-0.012 0.30 +/-0.010 6 4.5 16 2.85 55 2 16.83 17.41 18.04 18.72 20.24 UH2110300316 h
3 0/-0.012 0.50 +/-0.010 6 4.5 10 2.85 55 2 10.63 11.00 11.39 11.82 12.78 UH2110300510 h
3 0/-0.012 0.50 +/-0.010 6 4.5 16 2.85 55 2 16.83 17.41 18.04 18.72 20.24 UH2110300516 h
4 0/-0.012 0.20 +/-0.010 6 6 20 3.85 60 2 20.96 21.69 22.48 23.32 UH2110400220 h
4 0/-0.012 0.30 +/-0.010 6 6 12 3.85 55 2 12.69 13.14 13.61 14.12 15.27 UH2110400312 h
4 0/-0.012 0.30 +/-0.010 6 6 20 3.85 60 2 20.96 21.69 22.48 23.32 UH2110400320 h
4 0/-0.012 0.50 +/-0.010 6 6 12 3.85 55 2 12.69 13.14 13.61 14.12 15.27 UH2110400512 h
4 0/-0.012 0.50 +/-0.010 6 6 20 3.85 60 2 20.96 21.69 22.48 23.32 - UH2110400520 h
4 0/-0.012 1.00 +/-0.010 6 6 16 3.85 55 2 16.83 17.41 18.04 18.72 - UH2110401016 h
6 0/-0.015 0.50 +/-0.015 6 9 15 5.85 60 2 - UH2110600520 h
6 0/-0.015 1.00 +/-0.015 6 9 15 5.85 60 2 - - - - - UH2110601020 h
6 0/-0.015 2.00 +/-0.015 6 9 15 5.85 60 2 - - - - - UH2110602020 h
-
6.52
6.52
8.66
6.52
-
6.75
6.75
8.97
6.75
-
7.01
7.01
9.31
7.01
-
-
-
TYPHOO
N
HL
C-SD-TA
LFTA
SUTA
HSS-HSS
/CO
DRILLS
G2
MDTA
HF VH/U
P
MEF
ALU
MEX
UH
HSS/CO
-HSSP
END MIL
LS
CARBIDE
BURRS
h stock standard
f non-standard stock
m stock exhaustion
