UH- < 70HRC- Square

CUTTING PARAMETERS

INFO

UHLN2

TYPHOON TA-HTA-4HTA

Material Group ISO 513

P3 P4 P5 K2 K3 P6 K4 H1 H4 H5 H2 H3

TYPHOON PU-HPU

TYPHOON SUH

TYPHOON ALH

TYPHOON HRC

TYPHOON SUH MINI

TYPHOON HL

C-SD-TA

LFTA

SUTA

HSS-HSS / CO DRILLS

SQUARE RIB

Hardness / Rm < 45 HRC 45- 55 HRC 55- 60 HRC 60- 65 HRC

D( mm)

1.8

2.5

4 ap x ae ap x D ap x D ap x D ap x D Vc( m / min) 80-120 60-100 50-70 30-50

l1( mm) ap( mm) n( rpm) fn( mm / rev)

Vf( mm / min) n( rpm) fn( mm / rev)

Vf( mm / min)

≤ 6D	0.09	17700	0.028	990	14160	0.025	710	10620	0.022	475	7080	0.020	280
≤ 8D	0.08	15900	0.024	760	12720	0.021	540	9540	0.019	365	6360	0.017	210
≤ 10D 0.06		14200	0.020	560	11360	0.018	400	8520	0.016	265	5680	0.014	155
≤ 12D 0.05		12400	0.015	380	9920	0.014	270	7440	0.012	185	4960	0.011	105
≤ 15D 0.04		10600	0.013	270	8480	0.011	190	6360	0.010	130	4240	0.009	75
> 15D 0.03		8800	0.008	150	7040	0.008	110	5280	0.007	70	3520	0.006	40
≤ 6D	0.10	15900	0.030	950	12720	0.027	690	9540	0.024	460	6360	0.021	265
≤ 8D	0.09	14300	0.026	730	11440	0.023	530	8580	0.020	350	5720	0.018	205
≤ 10D 0.07		12700	0.021	530	10160	0.019	380	7620	0.017	255	5080	0.015	150
≤ 12D 0.06		11100	0.017	370	8880	0.015	260	6660	0.013	175	4440	0.012	105
≤ 15D 0.05		9600	0.014	260	7680	0.012	190	5760	0.011	125	3840	0.009	75
> 15D 0.03		9600	0.009	170	7680	0.008	120	5760	0.007	85	3840	0.006	50
≤ 6D	0.13	12700	0.035	890	10160	0.032	640	7620	0.028	425	5080	0.025	250
≤ 8D	0.11	11500	0.030	680	9200	0.027	490	6900	0.024	330	4600	0.021	190
≤ 10D 0.09		10200	0.025	500	8160	0.022	360	6120	0.020	240	4080	0.017	140
≤ 12D 0.07		8900	0.019	340	7120	0.017	250	5340	0.015	165	3560	0.013	95
≤ 15D 0.06		7600	0.016	240	6080	0.014	170	4560	0.013	115	3040	0.011	65
> 15D 0.04		7600	0.011	160	6080	0.009	110	4560	0.008	75	3040	0.007	45
≤ 6D	0.15	10600	0.040	850	8480	0.036	610	6360	0.032	405	4240	0.028	235
≤ 8D	0.13	9600	0.034	650	7680	0.031	470	5760	0.027	315	3840	0.024	185
≤ 10D 0.11		8500	0.028	480	6800	0.025	340	5100	0.022	230	3400	0.020	135
≤ 12D 0.08		7400	0.022	330	5920	0.020	230	4440	0.018	155	2960	0.015	90
≤ 15D 0.07		6400	0.018	230	5120	0.016	170	3840	0.014	110	2560	0.013	65
> 15D 0.05		6400	0.012	150	5120	0.011	110	3840	0.010	75	2560	0.008	45
≤ 6D	0.20	8000	0.050	800	6400	0.045	580	4800	0.040	385	3200	0.035	225
≤ 8D	0.17	7200	0.043	610	5760	0.038	440	4320	0.034	295	2880	0.030	170
≤ 10D 0.14		6400	0.035	450	5120	0.032	320	3840	0.028	215	2560	0.025	125
≤ 12D 0.11		5600	0.028	310	4480	0.025	220	3360	0.022	150	2240	0.019	85
≤ 15D 0.09		4800	0.023	220	3840	0.020	160	2880	0.018	105	1920	0.016	60
> 15D 0.06		4800	0.015	140	3840	0.014	100	2880	0.012	70	1920	0.011	40
