MEX - 30÷55HRC - Square
INFO
MEXLN2
OSAWA
NORM
<55
cylindrical shank, 2 flutes, extended and reduced neck
N
TYPHOO
HTA
TA-HTA-4
N
TYPHOO
PU-HPU
N
TYPHOO
SUH
P
M
+
N
TYPHOO
HRC + 1st choice
N
TYPHOO
I
SUH MIN SQUARE RIB
N
TYPHOO
HL
C-SD-TA
LFTA
SUTA
/CO
HSS-HSS
DRILLS
G2
MDTA
P
HF VH/U
MEF
ALU
MEX
UH
-HSSP
HSS/CO LS
END MIL
CARBIDE
BURRS
K
N
+
S
H
N
TYPHOO
ALH
+
, suitable
α
actual length according to _ angle
D D Tol. l l1 d1 L z 30’ 1° 1°30’ 2° 3° EDP No. Stock
0.2 0/-0.020
CR
CR Tol. d(h6)
4 0.3 0.5 0.16 50 2 0.57 0.59 0.61 0.63 0.68 MEXLN2002005 h
0.2 0/-0.020 4 0.3 1 0.16 50 2 1.09 1.12 1.16 1.21 1.30 MEXLN200201 h
0.2 0/-0.020 4 0.3 1.5 0.16 50 2 1.60 1.66 1.72 1.78 1.91 MEXLN2002015 h
0.3 0/-0.020 4 0.4 1 0.26 50 2 1.09 1.12 1.16 1.21 1.30 MEXLN200301 h
0.3 0/-0.020 4 0.4 2 0.26 50 2 2.12 2.19 2.27 2.35 2.53 MEXLN200302 h
0.3 0/-0.020 4 0.4 3 0.26 50 2 3.15 3.26 3.38 3.50 3.76 MEXLN200303 h
0.4 0/-0.020 4 0.6 2 0.37 50 2 2.12 2.19 2.27 2.35 2.53 MEXLN200402 h
0.4 0/-0.020 4 0.6 3 0.37 50 2 3.15 3.26 3.38 3.50 3.76 MEXLN200403 h
0.4 0/-0.020 4 0.6 4 0.37 50 2 4.19 4.33 4.49 4.65 5.00 MEXLN200404 h
0.4 0/-0.020 4 0.6 5 0.37 50 2 5.22 5.40 5.59 5.79 6.23 MEXLN200405 h
0.5 0/-0.020 4 0.7 2 0.45 50 2 2.16 2.23 2.31 2.40 2.57 MEXLN200502 h
0.5 0/-0.020 4 0.7 4 0.45 50 2 4.23 4.37 4.53 4.69 5.04 MEXLN200504 h
0.5 0/-0.020 4 0.7 6 0.45 50 2 6.29 6.51 6.74 6.98 7.51 MEXLN200506 h
0.5 0/-0.020 4 0.7 8 0.45 50 2 8.36 8.65 8.96 9.28 9.98 MEXLN200508 h
0.6 0/-0.020 4 0.9 2 0.55 50 2 2.16 2.23 2.31 2.40 2.57 MEXLN200602 h
0.6 0/-0.020 4 0.9 4 0.55 50 2 4.23 4.37 4.53 4.69 5.04 MEXLN200604 h
0.6 0/-0.020 4 0.9 6 0.55 50 2 6.29 6.51 6.74 6.98 7.51 MEXLN200606 h
0.6 0/-0.020 4 0.9 8 0.55 50 2 8.36 8.65 8.96 9.28 9.98 MEXLN200608 h
0.6 0/-0.020 4 0.9 10 0.55 50 2 10.43 10.79 11.17 11.57 12.44 MEXLN200610 h
0.7 0/-0.020 4 1.0 2 0.65 50 2 2.16 MEXLN200702 h
0.7 0/-0.020 4 1.0 4 0.65 50 2 4.23 4.37 4.53 4.69 5.04 MEXLN200704 h
0.7 0/-0.020 4 1.0 6 0.65 50 2 6.29 6.51 6.74 6.98 7.51 MEXLN200706 h
0.7 0/-0.020 4 1.0 8 0.65 50 2 8.36 8.65 8.96 9.28 9.98 MEXLN200708 h
0.7 0/-0.020 4 1.0 10 0.65 50 2
