KL-TECH s.r.o | www.klte.cz ALU - Ball nose CUTTING PARAMETERS INFO MDCAB2 N TYPHOO HTA TA-HTA-4 Material Group ISO 513 N1 N TYPHOO PU-HPU Material Alluminium ≤ 12% Si - Copper Alloy ap x ae N TYPHOO SUH Vc (m/min) ap N TYPHOO ALH N TYPHOO HRC N TYPHOO I SUH MIN N TYPHOO HL C-SD-TA LFTA SUTA /CO HSS-HSS DRILLS G2 MDTA P HF VH/U MEF ALU MEX UH -HSSP HSS/CO LS END MIL CARBIDE BURRS 522 ae COPYING D (mm) D (eff .) (mm) n (rpm) 1 1.5 2 2.5 3 4 5 6 8 10 12 0.80 1.20 1.60 2.00 2.40 3.20 4.00 4.80 6.40 8.00 9.60 40000 84930 63690 50960 42460 31850 25480 21230 15920 12740 10620 N2 N4 N5 Alluminium > 12% Si - Copper Alloy Brass and bronze Plastics 0.2D x 0.4D 0.2D x 0.4D 0.2D x 0.4D 0.2D x 0.4D 200-600 250-450 200-400 fn Vf (mm/rev) (mm/min) 0.013 0.017 0.017 0.021 0.025 0.035 0.045 0.053 0.067 0.080 0.094 1010 2850 2140 2140 2140 2230 2280 2260 2140 2030 1990 n (rpm) 111460 74310 55730 44590 37150 27870 22290 18580 13930 11150 9290 N3 fn Vf (mm/rev) (mm/min) 0.011 0.015 0.015 0.019 0.023 0.032 0.040 0.048 0.060 0.072 0.084 2530 2250 1690 1690 1690 1760 1800 1780 1680 1600 1570 n (rpm) 95540 63690 47770 38220 31850 23890 19110 15920 11940 9550 7960 600-1000 fn Vf (mm/rev) (mm/min) 0.010 0.013 0.013 0.017 0.020 0.028 0.036 0.043 0.054 0.064 0.075 1930 1710 1280 1280 1280 1340 1370 1360 1280 1220 1190 n (rpm) 254780 169850 127390 101910 84930 63690 50960 42460 31850 25480 21230 fn Vf (mm/rev) (mm/min) 0.013 0.017 0.017 0.021 0.025 0.035 0.045 0.053 0.067 0.080 0.094 6420 5710 4280 4280 4280 4460 4570 4520 4280 4070 3980
