G2 - General purpose - Square
G2410-11-12-13
OSAWA
NORM
<45
HRC
INFO
cylindrical shank, 4 flutes, long
TYPHOO
N
TA-HTA-4
HTA
G2410
TYPHOO
N
PU-HPU
G2411-G2412-G2413
P
M
K
N
S
TYPHOO
N
SUH
TYPHOO
N
ALH
H
+
,
+
,
+ 1st choice , suitable
TYPHOO
N
HRC
SIDE MILLING
TYPHOO
N
SUH MIN
I
D D Tol. d(h6) l L z EDP No. Stock
2 0/-0.030
C
C Tol.
4 9
l1
75 4 G2410020 h
2.5 0/-0.030 4 10 75 4 G2410025 h
3 0/-0.030 4 15 75 4 G2410030 h
3.5 0/-0.030 4 15 75 4 G2410035 h
4 0/-0.030 4 20 75 4 G2410040 h
4.5 0/-0.030 6 20 75 4 G2410045 h
5 0/-0.030 6 25 75 4 G2410050 h
6 0/-0.030 6 25 75 4 G2410060 h
3 0/-0.030 6 15 100 4 G2411030 h
4 0/-0.030 6 25 100 4 G2411040 h
5 0/-0.030 6 30 100 4 G2411050 h
6 0/-0.030 6 30 100 4 G2411060 h
7 0/-0.030 8 35 100 4 G2411070 h
8 0/-0.035 8 35 100 4 G2411080 h
9 0/-0.035 10 40 100 4 G2411090 h
10 0/-0.035 10 40 100 4 G2411100 h
11 0/-0.035 12 45 100 4 G2411110 h
12 0/-0.035 12 45 100 4 G2411120 h
8 0/-0.035 8 40 150 4 G2412080 h
10 0/-0.035 10 50 150 4 G2412100 h
12 0/-0.035 12 50 150 4 G2412120 h
16 0/-0.040 16 70 150 4 G2412160 h
18 0/-0.040 20 80 150 4 G2412180 h
20 0/-0.040 20 80 150 4 G2412200 h
16 0/-0.040 16 40 200 4 G2413160 h
20 0/-0.040 20 40 200 4 G2413200 h
TYPHOO
N
HL
C-SD-TA
LFTA
SUTA
HSS-HSS
/CO
DRILLS
G2
MDTA
HF VH/U
P
MEF
ALU
MEX
UH
HSS/CO
-HSSP
END MIL
LS
CARBIDE
BURRS
h stock standard
f non-standard stock
m stock exhaustion
