The WMF 1100 S is available with the following milk
and steam systems:
Technical data
WMF 1100 S Basic Milk
Recommended daily/
max. hourly output 2 Up to 80 cups
Nominal power rating/
mains power connection 1.9–2.3 kW /230 V
Output per hour according to
DIN 18873-2 2
Espresso / 2 espressos
Café crème / 2 café crèmes
Cappuccino
105 /150 cups
75 /90 cups
105 cups
-
Fresh milk beverages
An explanation of the milk systems and the beverages that can be prepared
using these can be found on pages 32 – 35.
Topping 1
1 or 2 integrated coffee bean hoppers/
expansion (choc or topping variant in
general only 1 coffee bean hopper) approx. 550 g /
with expansion approx. 1100 g
(fill volume depends on the size
of the coffee beans)
Choc or topping hopper (optional)/
expansion powder hopper (choc/
topping) approx. 450 g / with expansion
approx. 1250 g (fill volume depends
on the powder used)
SteamJet
-
Total hot water output/hour 110 cups (22 litres)
Energy loss per day according to
DIN 18873-2 Basic Milk/topping approx. 0.76 kWh /day
External dimensions (width /height 3 /
depth) 325 /500 /561 mm
Water tank approx. 4.5 litres
Empty weight depending on the
model 25.5 kg
Continuous sound pressure level
(LpA) 4 < 70 dB(A)
o steam boiler, so no Basic Milk, Basic Steam or SteamJet possi ble
N
Output is dependent on cup size, quality settings, spout, model and nominal power rating. The
recommended maximum daily output is based on our catalogued service concept. However, these
average values serve merely as a guideline. Let our trained WMF team match the ideal coffee machine
design to your specific needs.
3
Height including display. Height of top cover without display and expansions: 460 mm.
Height of product hopper expansion including lock but not key: 556 mm.
4
The A-rated sound pressure level LpA (slow) and LpA (impulse) at operating personnel work stations is
under 70 dB(A) in any operating mode.
Above 5°dKH (carbonate hardness) a
WMF water filter must be fitted.
1
2
Compact size
Thanks to its compact dimensions, the WMF 1100 S
fits easily underneath standard kitchen wall units
and can be used flexibly anywhere where space is
at a premium.
Intuitive touch display
The vertical swiping function on the intuitive
operating concept for the 7-inch touch display al-
lows for quick and directed guidance through the
various menus, making it much easier to operate,
not just in the self-service environment. Ease of cleaning
Patented Click&Clean function for easy cleaning
of the milk system. This saves on daily dismantling
of the milk foamer and reduces manual cleaning
to just once per week, even for our entry-level
model. Water tank
Large 4.5 litre water tank; water filter can be
integrated. Optional simple connection to constant
water supply (instant fitting kit to be installed by
trained technicians).
Pick colour accents
Serves every taste perfectly, even when it comes
to colour. The new WMF 1100 S is available in
different colour variants. Professional brewer and SteamJet
Designed for the professional field: the brewer
guarantees a long service life and top
performance. Tthe patented SteamJet
brings every cup to temperature in seconds. Product hopper
The capacity of the integrated product hoppers
can be extended significantly using the optional
bean and powder hoppers (lockable).
Fully automatic machines| WMF 65
