The WMF 1500 S is available with the following milk
and steam systems:
An explanation of the milk systems and the beverages that can be prepared
using these can be found on pages 32 – 35.
Technical data
Recommended daily/
max. hourly output 1 Up to 180 cups
Nominal power rating/mains
power connection 2.75 – 3.25 kW/220 – 240 V
Output per hour
according to DIN 18873-2 1
Espresso / 2 espressos
Café crème / 2 café crèmes
Cappuccino / 2 cappuccinos 124/194 cups
96/122 cups
124/194 cups
Cold milk beverages –
Cold milk foam beverages –
Total hot water
output/hour 143 cups
Energy loss per day
according to DIN 18873-2
Topping/Basic Milk 1.29 kWh
Coffee bean hopper Right approx. 650 g, central approx. 550 g
Choc or topping hopper
(optional) approx. 1200 g
External dimensions
(width/height 2 /depth) 325/675/590 mm
Water connections Water tank (approx. 4 litres) or constant
water supply
Empty weight
depending on the model approx. 35 kg
Continuous sound pressure
level (LpA) 3 < 70 db(A)
–
1.37 kWh
2.10 kWh
Performance was recorded using a machine with fixed water supply and is dependent on cup size,
quality settings, spout, model and nominal power rating. The basis for the recommended max. daily
capacity is the respective selected service concept. These average values are provided as a guide. Let
our trained WMF personnel put together a customised coffee machine solution for you.
2
Height with bean hopper with lock, no key.
3
The A-weighted sound pressure level LpA (slow) and LpA (impulse) in the operating personnel's work-
place is always under 70 dB in every mode of operation (A).
From 5° dKH (carbonate hardness), a WMF water filter must be fitted.
1
Dynamic Milk system
Hot and cold milk, hot and cold milk foam – fully
automatic via the beverage spout, without a separate
foamer chamber.
Ease of maintenance
Basic maintenance tasks can be carried out by the
operator. Your machine will be a rare sight for the
WMF service technician. Eight beverage buttons with six levels
Up to 48 beverages can be programmed in single
or double cups. Recipes and images can also be
stored. Small-Medium-Large function
Every beverage selected is easily assigned a
different predefined cup volume.
SteamJet/steam nozzle
Each cup is brought to temperature in seconds –
for the best coffee quality. Slender design
Small space requirement thanks to particularly
slender dimensions. This offers more options for
machine placement and combinations. Illuminated signals
The illuminated side parts serve as a visual
indicator of operating conditions.
Fully automatic machines| WMF 53
