Projeler/Projects: Ankara
Fotoğraf-Photo: Fethi Mağara
sıcaklık farkını kullanarak ısıtma ve soğutmadaki enerji
sarfiyatını minimize etmek üzere, bodrum katlardaki
otoparkların altına bir betonarme labirent tasarlanmış.
Yazın gece boyunca dış ortamdaki soğuk hava
bacalardan geçerek bu labirenti kat ederken, yoğun
beton kütlenin soğumasına ve adeta bir batarya gibi
bu soğukluğu hapsetmesine yardımcı oluyor. Gündüz
ise dışarıdaki sıcak hava bu bataryadan geçiriliyor,
soğuk beton kütle sayesinde sıcaklığını bırakıyor.
Esnek bir planla oluşturulmuş ofis birimlerine
ulaşan bu hava, yine betonarme döşemeler içerisine
yerleştirilen borulardan geçirilerek soğuk kirişlere
(chilled beam) ulaşıp, mekana bırakılıyor. Labirent, yer
altında olmasının etkisiyle, bölgenin senelik sıcaklık
ortalamasına sahip. Bu sayede kış aylarında gündüz
dış ortamdaki hava labirenti kat ettiğinde bu kez
ısınarak klima santrallerine ulaşıyor.
Bina şeffaf bir kabuğa sahip olmakla birlikte, güneşin
yönlenimi ve açılarına göre mevsimsel olarak ve
enerji modellemeleri ile test edilerek tasarlanan bir
ikinci katman vazifesi gören metal ızgara (mesh) ile
42 NATURA • MART - NİSAN 2014 / MARCH - APRIL 2014
local facilities with sustainable production techniques. Mainly three types
of stone were used in the building. One of them, ‘rustic green’ marble from
Kastamonu, applied in the northern and northwestern facade panel systems.
Galvanized steel axles applied the stone panels to the concrete mass, and
the spaces between these panels were regulated for draining rainwater. This
critical void also provided sharp details to the facade. The unprocessed finish
of the stone on the facade contrasts with the sharp finishes of the paneling
system, glass and metal components by uncovering the lower layers and
creating an organic feel. In addition to these stones, ‘basalt’ from Kayseri
was used in the outdoor floor with a patina finish and polished ‘tundra gray’
stone from Afyon region was used in the interiors.”
The most distinctive aspect of this project is undoubtedly the innovative
passive heating and cooling techniques used for the first time in Turkey in the
TCA building. Using the large temperature difference between day and night
that is the typical of climate conditions in Ankara in the central Anatolian
plateau the architect managed to minimize the energy consumption by
designing a system of reinforced concrete walls as a labyrinth under the
parking lot on the basement floors. The cold air outside is transferred to the
dense concrete mass of the labyrinth that stores the cool air before passing it
to a system of pipes. In contrast in daytime the heat is transported back through
the labyrinth decreasing in temperature through the cool concrete mass. The
