Dump-Lok Specifications
Overall Height
21 in.
Overall Width
5.25 in.
Overall Length
12.75 in.
Weight
37.5 lbs.
Max. Capacity
(Pairs)
95,000 lbs.
The Dump-Lok steel braces are
sold exclusively in pairs & are
strictly intended to be used as a
pair.
Dump-Lok can be used universally
on any brand of dump box.
Each year, hundreds of serious injuries
and fatalities occur when unsecured, or
improperly secured, dump beds fall while
workers are performing truck maintenance.
WorkSafe USA, Inc. is proud to present the
patented Dump-Lok dump truck and dump
trailer safety support device. Dump-Lok is
an engineering breakthrough in workplace
safety. The patented Dump-Lok steel braces
lock your truck’s dump bed in the raised
position, preventing it from falling in cases
of system failure or operator error. Plus,
Dump-Lok safely holds dump boxes at
angles higher than most manufacturer body
props, giving workers safe access to more
areas underneath the dump bed.
Dump-Lok has been independently tested
by the Structures and Materials Testing
Laboratory at the University of Wisconsin
- Madison to support a massive 95,000 lbs
(pairs).
The Occupational Safety & Health
Administration (OSHA) has issued citations
to employers for failing to provide lockout
procedures while employees were working
under the dump body of dump trucks.
OSHA recognizes the hazard of unsecured
dump beds, and has recommended using an
alternative “truck bed brace bracket”. (OSHA
SHIB 09-18-2006)
Dump-Lok is so unique & original that
it’s covered under United States Patent #
6905174.
All Dump-Lok products are
equipped with high grade, high
tensile steel safety chains to further
ensure safe repairs.
Dump-Lok can safely hold dump beds at
higher angles than manufacturer-provided
props, giving employees safe access to a
wider area underneath the dump bed.
Dump-Lok model # DL105 steel braces fit
up to a 4.5 inch flange - the standard dump
truck flange is 3.5 inches. Dump-Lok is
desi
