Carbon Steel-zinc coated / ASTM A563 Grade A |
ASME / ANSI B2.2 – 2015 |
ASTM F 1941 |
Class 2A fit; Class 2B thread; ASME B1.1 |
Stainless steel- SS316 / ASTM F594 |
ASME / ANSI B18.2.2 – 2015 |
Class 2A fit; Class 2B thread; ASME B1.1 |
Hex Nut-Heavy 1 / 4 " |
1 / 2 |
200 |
411751 |
Hex Nut-Heavy 3 / 8” |
11 / 16 |
100 |
411752 |
Hex Nut-Standard 3 / 8”( SS316) |
9 / 16 |
100 |
411775 |
Hex Nut-Heavy 1 / 2 " |
7 / 8 |
100 |
411753 |
Hex Nut-Standard 1 / 2 "( SS316) |
3 / 4 |
100 |
411776 |
Hex Nut-5 / 8” |
15 / 16 |
50 |
411754 |
Hex Nut-Standard 5 / 8”( SS316) |
15 / 16 |
50 |
411777 |
Hex Nut-3 / 4” |
1-1 / 8 |
25 |
411755 |
Hex Nut-Standard 3 / 4 " |
1-1 / 8 |
25 |
411778 |
1 Per MSS-SP-58-2002, the ultimate tensile loads are based on a tensile stress of 50,000 psi multiplied by the threaded rod root area based on coarse thread UNC. | |||
2 AISC Allowable Tensile load = 0.33 x Fu x Anom | |||
AISC Allowable Shear load = 0.17 x Fu x Anom | |||
Carbon steel-zinc coated / AISI 1005 thru 1035 |
ASME B18.21.1-2009 |
ASTM F1941 |
Stainless steel- SS316 / ASTM F594 |
ASME B18.21.1-2009 |
Table 407 – Ordering Information | ||||
Description |
Inside Diameter
( in)
|
Outside Diameter
( in)
|
Quantity
( Pack)
|
Item No. |
Washer 1 / 4 " |
0.312 |
0.734 |
200 |
411756 |
Washer 3 / 8” |
0.438 |
1.000 |
200 |
411757 |
Washer 3 / 8”( SS316) |
0.406 |
0.813 |
200 |
411780 |
Washer 1 / 2 " |
0.562 |
1.375 |
100 |
411758 |
Washer 1 / 2 "( SS316) |
0.531 |
1.250 |
100 |
411781 |
Washer 5 / 8” |
0.656 |
1.312 |
100 |
411759 |
Washer 5 / 8”( SS316) |
0.656 |
1.312 |
100 |
411782 |
Washer 3 / 4 " |
0.812 |
1.469 |
50 |
411760 |
Washer 3 / 4”( SS316) |
0.812 |
1.500 |
50 |
411783 |
Fender Washer 1 / 4 " |
0.281 |
1.250 |
100 |
411761 |
Fender Washer 1 / 4 "( SS316) |
0.281 |
1.250 |
100 |
411784 |
Fender Washer 3 / 8” |
0.406 |
1.500 |
100 |
411762 |
Fender Washer 3 / 8”( SS316) |
0.406 |
1.500 |
100 |
411785 |
Fender Washer 1 / 2 " |
0.531 |
2.000 |
100 |
411763 |
Fender Washer 1 / 2 "( SS316) |
0.531 |
2.000 |
100 |
411787 |
